• Height: 6” Depth: 2-1/2”
2900C Series Electric Baseboard - Heavy Duty Commercial Convection Heater
Features
Standard Models
• Bankers bronze with stainless steel heating element and Aluminum fins.
• Powder coated 22 gauge steel front with 20 gauge junction boxes located on
each end of the heater - junction boxes contain quick connect cable clamps and
6” ground lead wires.
• Standard inlet and outlet wire guards.
• Over-temperature thermal limit extends entire heated length of unit.
• A full length wireway provided along the back of the heater.
• Heater can be mounted to the wall by using the key hole knockouts every 4” at
the back of the heater.
• Optional In-Built thermostats field installed in the junction box.
• Made in U.S.A.
International Models
MFG CATALOG
NUMBER
MFG MODEL
NUMBER
WATTS
BTU’s
VOLTS
AMPS
HEATER
LENGTH (IN)
WT.
(LBS)
LIST
01038302
E2903-024C
375
1275
120
3.1
24
5
147
01038402
F2903-024C
375
1275
208
1.8
01038502
H2903-024C 375 / 281
1275 / 955
240 / 208
1.6 / 1.4
01038602
G2903-024C 375 / 281
1275 / 955
277 / 240
1.6 / 1.2
01038702
E2905-028C
500
1706
120
4.2
28
6
183
01038802
F2905-028C
500
1706
208
2.4
01038902
H2905-028C 500 / 375
1706 / 1275
240 / 208
2.1 / 1.8
01039002
G2905-028C 500 / 375
1706 / 1275
277 / 240
1.8 / 1.6
01039102
E2906-036C
600
2040
120
5.0
36
7
208
01039202
F2906-036C
600
2040
208
2.9
01039302
H2906-036C 600 / 450
2040 / 1530
240 / 208
2.5 / 2.2
01039402
G2906-036C 600 / 450
2040 / 1530
277 / 240
2.2 / 1.9
01039502
E2907-040C
750
2550
120
6.3
40
8
218
01039602
F2907-040C
750
2550
208
3.6
01039702
H2907-040C 750 / 563
2550 / 1914
240 / 208
3.1 / 2.7
01039802
G2907-040C 750 / 563
2550 / 1914
277 / 240
2.7 / 2.6
01039902
E2910-048C
1000
3413
120
8.3
48
10
252
01040002
F2910-048C
1000
3413
208
4.8
01040102
H2910-048C 1000 / 750
3413 / 2550
240 / 208
4.2 / 3.6
01040202
G2910-048C 1000 / 750
3413 / 2550
277 / 240
3.6 / 3.1
01040302
G2907-048C
750
2550
277
3.4
01040402
E2912-060C
1250
4250
120
10.4
60
12
300
01040502
F2912-060C
1250
4250
208
6.0
01040602
H2912-060C 1250 / 938
4250 / 3189
240 / 208
5.2 / 4.5
01040702
G2912-060C 1250 / 938
4250 / 3189
277 / 240
4.5 / 3.9
01040802
G2909-060C
938
3189
277
3.4
01040902
E2915-072C
1500
5100
120
12.5
72
14
345
01041002
F2915-072C
1500
5100
208
7.2
01041102
H2915-072C 1500 / 1125
5100 / 3825
240 / 208
6.3 / 4.7
01041202
G2915-072C 1500 / 1125
5100 / 3825
277 / 240
5.4 / 4.7
01041302
G2911-072C
1125
3825
277
4.1
01041402
F2917-084C
1750
5950
208
8.4
84
16
383
01041502
H2917-084C 1750 / 1313
5950 / 4464
240 / 208
7.3 / 6.3
01041602
G2917-084C 1750 / 1313
5950 / 4464
277 / 240
6.3 / 5.5
01041702
G2913-084C
1313
4464
277
4.7
01041802
F2920-096C
2000
6826
208
9.6
96
18
423
01041902
H2920-096C 2000 / 1500
6826 / 5100
240 / 208
8.3 / 7.2
01042002
G2920-096C 2000 / 1500
6826 / 5100
277 / 240
7.2 / 6.3
01042102
G2915-096C
1500
5100
277
5.4
01042602
F2925-120C
2500
8532
208
12.0
120
22
444
01042702
H2925-120C 2500 / 1875
8532 / 6375
240 / 208
10.4 / 9.0
01042802
G2925-120C 2500 / 1875
8532 / 6375
277 / 240
9.0 / 7.8
01042902
G2918-120C
1875
6375
277
6.8
MFG CATALOG
NUMBER
MFG MODEL
NUMBER
WATTS
BTU’s
VOLTS
AMPS
HEATER
LENGTH (IN)
WT.
(LBS)
LIST
01180502
M2903-024CI
375
1275
220
1.7
24
5
147
01180602
H2903-024CI
240
240
01180702
M2905-028CI
500
1706
220
2.3
28
6
183
01180802
H2905-028CI
240
2.1
01180902
M2906-036CI
600
2040
220
2.7
36
7
208
01181002
H2906-036C
240
2.5
01181102
M2907-040CI
750
2550
220
3.4
40
8
218
01181202
H2907-040C
240
3.1
01181302
M2910-048CI
1000
3413
220
4.6
48
10
252
01181402
H2910-048CI
240
4.2
01181502
M2912-060CI
1250
4250
220
5.7
60
12
300
01181602
H2912-060C
240
5.2
01181702
M2915-072CI
1500
5100
220
6.8
72
14
345
01181802
H2915-072CI
240
6.3
01181902
M2917-084CI
1750
5950
220
8.0
84
16
383
01182002
H2917-084CI
240
7.3
01182102
M2920-096CI
2000
6826
220
9.1
96
18
423
01182202
H2920-096CI
240
8.3
01182302
M2925-120CI
2500
8532
220
11.4
120
22
444
01182402
H2925-120CI
240
10.4
