Electric Baseboard - Accessories
Blank Sections Optional Wireway Covers
In-Built Thermostat Kits
Field Installed Accessories
**Not for use with 24A06G-1 relay.
*Junction box covers supplied with baseboard heater will work in conjunction with in-built thermostat kits.
IVORY & WHITE
DESCRIPTION WT.
(LBS) LIST
MFG CATALOG
NUMBER
MFG MODEL
NUMBER
01054602 TBS SPST-In-Built 22A@ 120-240V 18A@ 277V (0O-110FO ) 1/2 44
01054702 TBD DPST-In-Built 22A@ 120-240V 18A@ 277V (0O-110F O) 1/2 57
DESCRIPTION
IVORY WHITE BANKERS BRONE
WT.
(LBS) LIST
MFG CATALOG
NUMBER
MFG MODEL
NUMBER
MFG CATALOG
NUMBER
MFG MODEL
NUMBER
MFG CATALOG
NUMBER
MFG MODEL
NUMBER
Disconnect Switch, 20
Amp, 120-277V 01061002 DS 01061102 DSW 01061202 DSB
1
85
Corner Sections 01054902 CS 01055002 CSW 01055102 CSB 38
1” Joiner Kits 01055202 JK 01055302 JKW 01055402 JKB 1/4 26
6” Blank Relay Section
(Relay Not Included)** 01055502 LVRS 01055602 LVRSW 01055702 LVRSB 1 1/2 103
Receptacle Section
(Baseboard Mounted)
15 Amp 120 VAC
01055802 BDR115 01055902 BDR115W 01056002 BDR115B 1/4 26
Receptacle Section
(Mounted in 6” Blank)
15 Amp 120 VAC
01056102 DR115 01056202 DR115W 01056302 DR115B
2
120
Transfer Switch
(Mounted in 6” Blank)
16 Amp 120 VAC
01056402 SR120 01056502 SR120W 01056602 SR120B 151
Transfer Switch
(Mounted in 6” Blank)
16 Amp 240 VAC
01056702 SR220 01056802 SR220W 01056902 SR220B 184
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
LENGTH
(in.)
COVER
LENGTH
(in.)
WT.
(LBS) LIST
01057002 WWA01 24” 20 1 37
01057102 WWA02 28” 24 1.5 40
01057202 WWA03 36” 32 2 43
01057302 WWA04 40” 36 2.5 50
01057402 WWA05 48” 44 3 52
01057502 WWA06 60” 56 4 55
01057602 WWA07 72” 68 5 62
01057702 WWA08 84” 80 6 72
01057802 WWA09 96” 92 7 82
01057902 WWA00 120” 116 8 99
LENGTH
IVORY WHITE BANKERS BRONZE
WT.
(LBS)
IVORY
WHITE
LIST
BRONZE
LIST
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
24” 01058002 BBS024A 01059002 BBS024AW 01060002 BBS024C 5 57 117
28” 01058102 BBS028A 01059102 BBS028AW 01060102 BBS028C 5 1/2 62 127
36” 01058202 BBS036A 01059202 BBS036AW 01060202 BBS036C 6 76 147
40” 01058302 BBS040A 01059302 BBS040AW 01060302 BBS040C 7 81 155
48” 01058402 BBS048A 01059402 BBS048AW 01060402 BBS048C 8 91 159
60” 01058502 BBS060A 01059502 BBS060AW 01060502 BBS060C 10 109 220
72” 01058602 BBS072A 01059602 BBS072AW 01060602 BBS072C 12 130 242
84” 01058702 BBS084A 01059702 BBS084AW 01060702 BBS084C 15 137 274
96” 01058802 BBS096A 01059802 BBS096AW 01060802 BBS096C 17 160 307
120” 01058902 BBS120A 01059902 BBS120AW 01060902 BBS120C 20 195 387
