RPH Series Pump House Convection Specialty Heater
• Provides protection against freezing for pump houses, utility rooms,
relay stations, construction sheds, etc.
• Aluminum finned heating element
• Powder coated epoxy steel case
• Automatic temperature control thermostat with a 30
o
F to 140
o
F range.
• Dimension 20” x 5-1/2” x 4”
• Made in U.S.A.
FH Series In-Floor Fan Forced Specialty Heater
• Powder coated 20 gauge steel case
• 14 gauge grill
• Steel spiral finned heating element
• Auto reset thermal cut out with audible alarm.
• Floor opening: 14-1/8” x 7-1/4” x 7-3/8”
• Grill dimensions: 15-13/16” x 8-13/16”
• Made in U.S.A.
• Fits into soffits, stair risers or under utility cabinets
• Finned steel heating element.
• Manual reset thermal cut-out
• Recessed opening: 22-3/8” x 3-5/8” x 11-1/2”
• Grill dimensions: 23-7/8 x 3-5/16
• Made in U.S.A.
TSH Series Fan Forced Kickspace Specialty Heater
Standard Models
Standard Models
Standard Models
Specialty Heaters
• Use under desks for personal comfort or
in small areas for freeze protection or
moisture removal.
• Built in stand.
• Temperature control thermostat.
• 6' long - 3 conductor cord
• Made in U.S.A.
Width: 22-3/4”
Height: 8”
Depth: 1-3/4”
Standard Models
“Under-The-Desk” Confined Space Radiant Heat Panel
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
WATTS
BTU’s
VOLTS
AMPS
WT.
(LBS)
LIST
09990802
RPH1-5A
500
1706
120
4.2
5
213
09990902
RPH2-5A
500
1706
240
2.1
5
International Models
09842602
RPH22-5Ai
500
1706
220
2.3
5
213
09842702
RPH2-5Ai
240
2.1
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
WATTS
BTU’s
VOLTS
AMPS
WT.
(LBS)
LIST
03782302
FH15
750
2560
120
6.25
15
608
1500
5120
120
12.5
1500/1125
5120 / 3840
240/208
6.25/5.41
OPTIONAL FIELD INSTALLED THERMOSTATS
03782702
FH1T
Single Pole Integral Thermostat Kit
1
161
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
WATTS
BTU’s
VOLTS
AMPS
WT.
(LBS)
LIST
03818002
TSH20J
1500 / 1000
5120 / 3412
120
12.5 / 8.4
16
364
1500 / 750
5120 / 2560
208
7.2 / 3.6
2000 / 1000
6284 / 3412
240
8.4 / 4.2
09701702
TSH20JW
Above Model with White Grill
OPTIONAL FIELD INSTALLED THERMOSTATS
03783702
TSH1TX
Single Pole Integral Thermostat Kit
1
84
03783802
TSH2TX
Double Pole Integral Thermostat Kit
1
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
WATTS BTU’s
VOLTS PHASE WT.
(LBS)
LIST
04508802 170-TS
170
580
120
1
9
167
