VCX TYPE
Features
Standard Models
Illuminated Florescent Magnifiers
• 5", 8-diopter (3X power) magnifying clear lens for 200% magnification of an
object with a focal length of 5"
• Suspension spring balanced arm assembly allowing up to 45" reach, with finger
tighten control knobs to lock arms and shade into position
• 6’ cordset with 2 prong polarized plug
• Housing consists of a sturdy white plastic 8-1/2” shade with an on-off rocker
switch and glare protection cover located on the top of the shade
• Includes die-cast clamp-on base to attach to a flat surface up to 2-1/2” thick
• Factory installed 22W, 120V, T-9 deluxe cool white circline florescent lamp and
protective lens
• Imported to TPI specifications.
Features
Standard Models
Incandescent
Features
• Chrome plated, flexible arm
• 8’ 18/3 or 18/2 SPT cordset with molded plug
• Turn knob on-off switch
• Phenolic shade with spun Aluminum inner reflector on R - Series
• Bulb not included
• Imported to TPI specifications.
Standard Models
12-R-M-3
• Patented disc and collar swivel joints with adjustable bar knobs for securing arms into a
variety of positions
• Shades constructed of a 22 Gauge steel and arms made of 5/8" steel tubing, with reach
from 25" to 44"
• Charcoal gray powder coated finish
• Horizontal or vertical bolt down mounting bracket
• 10 amp rocker type on-off switch and lamp socket
• Includes an 8' 18/3 SJTO Cordset with NEMA 5-15 molded grounded plug for 120V
operation
• Bulb not included with VCX Models
• Made in U.S.A.
Medium Duty, Flexible Arm, Incandescent, Machine Tool Lights
Heavy Duty Machine Tool Lights
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
BULB TYPE BULB
DESCRIPTION WATTS MAX
LUMENS
AVE. BULB
LIFE (HRS)
OVER-ALL
REACH
WT.
(LBS)
LIST
03812101 55-VCX-701B
Incandescent
100W medium
base A-19, R-30
or PAR 38
100 1470
750
29”
6
201
03813101 66-VCX-701B
38”
210
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
BULB
BASE
MAX
LUMEN
OVER-ALL
REACH
WT.
(LBS)
LIST
04423002 12-R-M-3
60 Watt
Magnetic Base
865
12”
3
137
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
MAGNIFICATION
POWER
BULB WATTS MAX
LUMENS
AVE. BULB
LIFE (HRS)
OVER-ALL
REACH
WT.
(LBS)
LIST
04851502
45-MAG-W
3X
22W. Circline
22
1800
16,000
45”
10
236
03120302
MAG-22W
22W., 120V., T-9 deluxe cool white circline replacement lamp
1
31
