4800 Series Register Style Fan Forced Wall Heater - With Wall Box
Features
• Units have white powder coat finish.
• Powder coated 20 gauge steel front.
• Manual reset thermal limit.
• Finned tubular steel element.
• Propeller style fan blade - 2200 RPM / 70 CFM.
• Rough in dimensions: 14-1/2”Wide x 7-1/8” High x 3-1/2” Deep.
• Grill dimensions:
16-3/4”Wide x 7-5/8” High.
• Unit not approved for ceiling mount applications.
• Left discharge only. / Weight: 9lbs
• Made in U.S.A.
Accessories
Standard Models
MFG CATALOG
NUMBER
MFG MODEL
NUMBER
VOLTS
WATTS
MAX
BTU’S
AMPS
DOUBLE POLE IN-BUILT THERMOSTAT (0º - 110º F TEMPERATURE RANGE)
03281502
F4820T2RPW
208
2000
6826
9.6
03281602
HF4875T2RPW
240/208
750 / 562
2560 / 1920
3.1 / 2.7
03281702
HF4810T2RPW
1000 / 750
3413 / 2560
4.2 / 3.6
03281802
HF4815T2RPW
1500 / 1125
5120 / 3840
6.3 / 5.4
03281902
HF4820T2RPW
2000 / 1500
6826 / 5120
8.3 / 7.2
SINGLE POLE IN-BUILT THERMOSTAT (0º - 110º F TEMPERATURE RANGE)
03282002
E4875TRPW
120
750
2560
6.25
03282102
E4810TRPW
1000
3413
8.33
03282202
E4815TRPW
1500
5120
12.5
03282302
F4820TRPW
208
2000
6826
9.6
NO IN-BUILT THERMOSTAT
03282402
E4875RPW
120
750
2560
6.25
03282502
E4810RPW
1000
3413
8.33
03282602
E4815RPW
1500
5120
12.5
03282702
F4820RPW
208
2000
6826
9.6
03282802
HF4875RPW
240/208
750 / 562
2560 / 1920
3.1 / 2.7
03282902
HF4810RPW
1000 / 750
3413 / 2560
4.2 / 3.6
03283002
HF4815RPW
1500 / 1125
5120 / 3840
6.3 / 5.4
03283102
HF4820RPW
2000 / 1500
6826 / 5120
8.3 / 7.2
MFG CATALOG
NUMBER
MFG MODEL
NUMBER
DESCRIPTION
WT.
(LBS)
03284502
4300EX8W
1” SEMI RECESSING EXTENDER
2
03284602
4300EX16W
2” SEMI RECESSING EXTENDER
3
03284702
4300EX32W
4” SURFACE MOUNTING FRAME
4
03284802
4300PW
WALL PLATE ADAPTOR (OD 21.5” x 12.25”)
1
03297702
43T
SINGLE POLE THERMOSTAT 0
O
- 110
O
F
1
03297902
48T2
DOUBLE POLE THERMOSTAT 40
O
- 110
O
F
1
