25 / 117
25
25”
11-11/16”
4-1/16”
Knockouts
12”
24”
44”
56”
1/4”Dia. Mounting Holes
3/5 KW = 33”
6/10 KW = 46”
1/2”, 3/4”Conduit
1/2”, 3/4”Conduit
1/2”, 1-1/2”Conduit
2-3/4”
2-3/8”
3-3/8”
9“
25”
1-9/16”
3“
Mounting Hole Locations
(Back View of Unit)
Product Dimensions
Product Features (2-24 KW; All Voltages)
Stocked Models & Features
•0 1 / 3 phase field convertible with 24 Volt control circuit.
•0 Disconnect switch, dust filter, & high low operation.
•0 Built-in thermostat and field convertible for remote thermostat.
Accessories
• For commercial and institutional application such as stores,
schools, offices, transportation terminals, churches, entrance
ways.
• Wall or ceiling mount; surface, semi-recessed or fully
recessed.
• (8) air inlet and outlet configurations.
• Capacities from 2-24 KW with 230 to 1,000 CFM
• Motors are two speed, shaded pole, resilient mounted, direct
drive. High/low heat and blower speed offer versatility.
• ETL Listed.
• Beige powder coated finish
• Choice of eight standard control options include unit or wall
mounted 120 or 24V thermostats, with or without built-in
control transformers.
• Industrial type finned tubular elements.
• Easily removable fan and element decks for simplified
maintenance.
• Full length thermal protection.
• Limited warranty-one year.
*Factory wired for 3-phase, field convertible to 1-phase.
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
SIZE
DESCRIPTION
LIST
DUCT COLLAR
04415602 DC-33 33"
The same model is used for the inlet or outlet.
If duct collars are required for both inlet &
outlet then 2 must be ordered.
192
04415702 DC-46 46"
233
04415802 DC-66 66"
292
04415902 DC-79 79"
356
RECESSING TRIM FRAMES
04537802 TF-33 33"
Recessing Trim Frames should be ordered
to "trim-out" any recessed or semi-recessed
installation.
174
04537902 TF-46 46"
195
04538002 TF-66 66"
244
04538102 TF-79 79"
268
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
SIZE
LIST
Fresh Air Make-Up Intake Flange & Kickbase
07715802
FAM33
33"
379
07715902
FAM46
46"
436
07716002
FAM66
66"
671
07716102
FAM79
79"
738
Kickbase (Pedestal) ONLY
07715402
KB33
33"
151
07715502
KB46
46"
160
07715602
KB66
66"
193
07715702
KB79
79"
211
6300 Series Multiple Angle Cabinet Unit Heater
HEATER
LENGTH
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
HIGH
LOW
VOLTS PHASE WT.
(LBS)
LIST
KW BTU’s AMPS CFM KW BTU’s AMPS CFM
33”
06671402 6333D052033B30D0F
5 17065
25.0 / 17.6
250 3 10239
15.4 / 9.2
230
208
1-3*
99
3205
06671502 6333D052433B30D0F
21.8 / 15.4
13.5 / 8.2
240
1-3*
06670802 6333D054833B30D0F
7.8
4.6
480
3
46”
06671902 6346D102433B30D0F
10 34130
43.6 / 30.7
500 6 20478
26.9 / 16.2
460
240
1-3*
130
3717
06672002 6346D104833B30D0F
15.4
8.1
480
3
International Models
33”
04736202 6333D053834B30D0F1
5 17065
7.6
250 3 10239
4.56
230
380
3
(4-Wire)
99
3205
04736302 6333D054134B30D0F1
6.97
4.18
415
46”
04736402 6346D103834B30D0F1
10 34130
15.2
500 6 20478
9.12
460
380
130
3717
04736502 6346D104134B30D0F1
13.94
8.36
415
