HOW TO DESIGNATE A MODEL:
Series Number
Element KW
3KW through 18KW
See model chart for KW options.
Element Voltage
F = 208V H = 240V G = 277V
P = 480V
Phase
1 = Single Phase 3 = Three Phase
Control System
Blank = None
T = Unit Thermostat
SSR = SSR Control
Motor Voltage
E = 120 G = 277 P = 480
Heater Stages
Blank = One 2 = Two
F 3 E 73 15 2 T
Product Specifications
• 20 gauge galvanized cabinet.
• Variable speed motor, factory set at maximum. Motor speed
can be field adjusted to increase heat rise.
• Acoustically insulated with 1” fiberglass.
• Access panels on bottom of unit.
• 24 Volt controls. / Disconnect switch
• Air flow switch.
• Terminal blocks.
• Single point connection.
• Dust tight control enclosure.
• Filter rack on inlet with throw away filter.
• Inlet and outlet screens and duct connection.
• Automatic primary limit control.
• Optional wall thermostat, unit thermostat or SSR control
which proportionally regulates heat output.
• Made in U.S.A.
Standard Models
The 7300 Series LowBoy Plenum Heater is designed to fit jobs where the clear space between the ceiling
and the floor above is as small as 11-3/4 inches.
7300 Series Plenum Heater
SSR proportional control maximum: 45 Amps
Note: Products listed in this section are custom built and subject to 100% cancellation/restock charges.
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
KW CFM
RANGE
VOLTS/
PHASE
TOTALAMPS for
MOTOR & HEATER STAGE MOTOR
VOLTAGE
FULL LOAD AMPS
for MOTOR ONLY
MOTOR
H.P.
WT.
(LBS)
06180702
F1G7305
5
170-950
208/1
26
1
208
2
1/4
163
06175402
H1G7305
240/1
22
240
06063002
G1G7305
277/1
20
277
06176402
F3G7305
208/3
15
208
2
05344502
H3G7305
240/3
14
240
05346002
P3P7305
480/3
8
480
06099602
F3E7310
10
208/3
32
1
208
4
06177302
H3G7310
240/3
26
240
2
06180602
P3P7310
480/3
14
480
2
06063602 F3E7310-2
208/3
32
2
120
4
05344602 H3G7310-2
240/3
26
240
2
05346102 P3P7310-2
480/3
14
480
2
05344802
H3G7312
12
270-1500
240/3
32
1
240
3
2 Motors @
1/4 HP Each 219
05346202
P3P7312
480/3
17
480
3
06085902 F3E7312-2
208/3
41
2
120
8
05345002 H3G7312-2
240/3
32
240
3
05346302 P3P7312-2
480/3
17
480
3
05345202
H3G7315
15
240/3
39
1
240
3
06177702
P3P7315
480/3
21
480
3
06181002 F3E7315-2
208/3
49
2
120
8
06085102 H3G7315-2
240/3
39
240
3
05346402 P3P7315-2
480/3
21
480
3
05346502
P3P7318
18
480/3
25
1
480
3
05346602 P3P7318-2
480/3
25
2
480
3
