HLA Series Hazardous Location Fan Forced Unit Heater
Factory Installed Accessories & Physical Dimensions
(Top View)
(Front View)
(Side View)
(Rear View)
MFG
MODEL A B
C
D E F G
3 ph.
1 ph.
HLA 12 17 3/4 22 3/8 19 3/4 20 5/8 16 1/4 10 1/2 14 3
HLA 16 20 3/4 26 3/8 20 3/4 21 5/8 20 1/4 11 1/2 18 4
HLA 20 24 3/4 30 3/8 22 1/2 N/A 24 1/4 12 1/2 22 4 1/2
PHLA Series Portable Hazardous Location Fan Forced Unit Heater
• 3.0 through 25 KW rating
• 208, 240, 480, 600 Volt available in selected capacities
• Cart has anti-static wheels to reduce the risk of static discharge
• Wheeled cart allows for easy maneuverability
• Cart has integrated fork-lift channels to provide ease of lifting on to
ramps or trucks
• Excellent for providing seasonal heating in hazardous environments
• All units have disconnect switch, pilot light, and thermostat - standard
• 24 Volt control, transformer, and contactor in NEMA 7 enclosure
• Durable epoxy coating on heater housing
• Hazardous location unit mounted male / female plug
• Adjustable louvers; manual reset
• Made in U.S.A.
Standard Portable Hazardous Location Models
SUFFIX
DESCRIPTION
T
In-Built single pole thermostat 50° - 90° F
120
Control transformer w/ primary fusing (Delete 24 suffix - add 120)
208
208/240V Control available on 208/240V units
(Delete 24 suffix and add 208 OR 240)
240
D
Disconnect Switch
P
Pilot Light
MFG CATALOG
NUMBER
MFG MODEL
NUMBER
KW BTU VOLTS PH AMPS TEMP
RISE F
AIR
THROW CFM WT.
(LBS)
07393402
PHLA12-208160-3.0-24-TDP
3 10,250
208
1
16.3
16.5
24’
580
260
07393302
PHLA12-208360-3.0-24-TDP
208
3
9.8
07393202
PHLA12-240160-3.0-24-TDP
240
1
14.8
07393102
PHLA12-240360-3.0-24-TDP
240
3
8.6
07393002
PHLA12-480360-3.0-24-TDP
480
3
4.3
07394302
PHLA12-600360-3.0-24-TDP
600
3
3.5
07392902
PHLA12-208160-5.0-24-TDP
5 17,100
208
1
26
27.6
24’
580
07392802
PHLA12-208360-5.0-24-TDP
208
3
15.4
07392702
PHLA12-240160-5.0-24-TDP
240
1
23.1
07392602
PHLA12-240360-5.0-24-TDP
240
3
13.4
07392502
PHLA12-480360-5.0-24-TDP
480
3
6.7
07394202
PHLA12-600360-5.0-24-TDP
600
3
5.4
07392402
PHLA12-208160-7.5-24-TDP
7.5 25,600
208
1
38
41.4
24’
580
07392302
PHLA12-208360-7.5-24-TDP
208
3
22.3
07392202
PHLA12-240160-7.5-24-TDP
240
1
33.6
07392102
PHLA12-240360-7.5-24-TDP
240
3
19.4
07392002
PHLA12-480360-7.5-24-TDP
480
3
9.7
07394102
PHLA12-600360-7.5-24-TDP
600
3
7.8
07391902
PHLA16-208360-10.0-24-TDP
10 34,150
208
3
29.3
21.7
40’
1500 305
07391802
PHLA16-240160-10.0-24-TDP
240
1
44
07391702
PHLA16-240360-10.0-24-TDP
240
3
25.5
07391602
PHLA16-480360-10.0-24-TDP
480
3
12.7
07394002
PHLA16-600360-10.0-24-TDP
600
3
10.2
07391502
PHLA20-208360-15.0-24-TDP
15 51,200
208
3
43.5
19.2
43’
2450
350
07391402
PHLA20-240360-15.0-24-TDP
240
3
38.1
07391302
PHLA20-480360-15.0-24-TDP
480
3
19
07393902
PHLA20-600360-15.0-24-TDP
600
3
15.2
07391202
PHLA20-480360-20.0-24-TDP
20 68,300 480
3
25.1
26.2
43’
2450
07393802
PHLA20-600360-20.0-24-TDP
600
3
20
07391102
PHLA20-480360-25.0-24-TDP
25 85,400 480
3
31.1
32.8
43’
2450
07393702
PHLA20-600360-25.0-24-TDP
600
3
24.9
