UH Series Horizontal Fan Forced Unit Heater
Standard Product Models
Factory & Field Installed Accessories
NOTE:
Factory installed heat purge fan delay option (F) requires
unit to have CA1 or CA2 factory installed
FACTORY INSTALLED OPTIONS
LIST
SUFFIX
DESCRIPTION
F
Heat purge fan delay switch for 208 / 240 / 277V units
219
(includes contactor & transformer)
Heat purge fan delay switch for 480V units
127
(contactor & transformer standard in unit)
S
Summer fan switch
63
CA1 24v Transformer (3.3 KW - 15 KW units) & Contactor
160
CA2 120v Transformer (3.3 KW - 15 KW units) & Contactor
E
Epoxy Coating
121
T
SPST Thermostat (40
O
F - 110
O
F)
74
D
Disconnect Switch - 30 Amps
305
Disconnect Switch - 40 Amps
350
Disconnect Switch - 80 Amps
439
Disconnect Switch - 100 Amps
445
FIELD INSTALLED ACCESSORIES
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
DESCRIPTION
LIST
06462302 DCS303
30 Amp Disconnect Kit
260
06462402 DCS403
40 Amp Disconnect Kit
306
06462502 DCS803
80 Amp Disconnect Kit
401
06462602 DCS1003
100 Amp Disconnect Kit
404
06879902 TUH1 25 Amp SPST Thermostat
Kit (40
O
F - 110
O
F)
74
06991002 UHB-1 wall / ceiling bracket - 3.3 KW - 15 KW units
108
06991102 UHB-3 wall / ceiling bracket - 20 KW - 30 KW units
122
06991202 UHB-4 wall / ceiling bracket - 35 KW - 48 KW units
155
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
KW BTU’S VOLTS PH AMPS CONTROL
VOLTS
TEMP
RISE °F
AIR
THROW CFM RECOM’D
MOUNTING HT.
WT.
(LBS)
LIST
06446002 F1FUH03003
3.3 11200
208
1
15.9
208
26
26’
400
9’
36
736
06446602 H1HUH03003
240
1
13.8
240
06447202 G1GUH03003
277
1
11.9
277
07114802 H3HUH03C03
240
3
7.9
240
07114902 F3FUH03C03
208
3
9.2
208
07114002 P3PUH03CA1
480
3
4
24
938
06446102 F1FUH05003
5 17100
208
1
24.1
208
40
26’
400
9’
36
769
06446702 H1HUH05003
240
1
20.8
240
06447302 G1GUH05003
277
1
18.1
277
06449302 F2FUH05C03
208 1 or 3 24.1 / 14.0 208
44
06449402 H2HUH05C03
240 1 or 3 20.8 / 12.1 240
06448802 P3PUH05CA1
480
3
6.1
24
1017
07180502 F1FUH07CA1
7.5 25600
208
1
36.1
24
42
36’
575
9’
40
1185
07173702 H1HUH07CA1
240
1
31.3
24
41
07151802 G1GUH07CA1
277
1
27.1
24
41
06447902 F3FUH07C03
208
3
20.8
208
44
06449502 H2HUH07C03
240 1 or 3 31.3 / 18.1 240
06448902 P3PUH07CA1
480
3
9.1
24
1279
07170902 F1FUH10CA1
10.0 34100
208
1
48.1
24
55
36’
575
9’
42
1306
06808402 H1HUH10CA1
240
1
41.7
24
07173802 G1GUH10CA1
277
1
36.1
24
06449602 F2FUH10C03
208 1 or 3 48.1 / 27.8 208
06449702 HF2BUH10C03 10 / 7.5 34100 240 1 or 3 41.7 / 24.1 240
55
45
25600 208 1 or 3 36.1 / 20.8 208
42
07114202 P3PUH10CA1 10.0 34100 480
3
12.1
24
55
51
1354
06446402 F1FUH12C03
12.5 42600
208
1
60.1
208
49
45’
800
10’
45
2102
06447002 H1HUH12C03
240
1
52.1
240
06448102 F3FUH12C03
208
3
34.7
208
06448602 H3HUH12C03
240
3
30.1
240
07114302 P3PUH12CA1
480
3
15.1
24
2186
06446502 F1FUH15CO3
15.0 51200
208
1
72.1
208
59
45’
800
10’
54
2313
06447102 H1HUH15C03
240
1
62.5
240
06448202 F3FUH15C03
208
3
41.7
208
06448702 H3HUH15C03
240
3
36.1
240
07114402 P3PUH15CA1
480
3
18.1
24
2405
06883002 F1FUH20CA1
20.0 68300
208
1
96.2
24
47
56’
1350
13’
55
3174
06884202 H1HUH20CA1
240
1
83.3
24
06883102 F3FUH20CA1
208
3
55.6
24
06884302 H3HUH20CA1
240
3
48.2
24
06883202 P3PUH20CA1
480
3
24.1
24
06884402 F1FUH25CA1
25.0 85300
208
1
120.2
24
58
56’
1350
13’
55
3740
06883302 H1HUH25CA1
240
1
104.2
24
06884502 F3FUH25CA1
208
3
69.5
24
06883402 H3HUH25CA1
240
3
60.2
24
06884602 P3PUH25CA1
480
3
30.1
24
06884702 H1HUH30CA1
30.0 102390
240
1
125
24
70
56’
1350
13’
60
4331
06883602 F3FUH30CA1
208
3
83.4
24
06884802 H3HUH30CA1
240
3
72.3
24
06883702 P3PUH30CA1
480
3
36.1
24
06884002 P3PUH40CA1 40.0 136500 480
3
48.2
24
55
56’
2275
16’
75
5535
06887802 P3PUH48CA1 48.0 163800 480
3
57.8
24
67
56’
2275
16’
78
6910
