HOW TO DESIGNATE A MODEL:
Unit Length (Inches)
24, 36, 48, 60, or 72
Total Wattage
Series Number
Cabinet Size
25=11”H x 4”D 45=20”H x 5”D
Voltage/Phase
F=208V, 1 Phase G=277V, 1 Phase
H=240V, 1 Phase J=208V, 3 Phase
K=240V, 3 Phase
Control Option
Blank=None
T or T2=Thermostat R, R2, or R9=Relay
(See control option chart)
M41 25 F 48 1000 T
4100 Series Recessed Commercial Wall Convector
M4125 Dimensions - Cabinet Sizes 4” Deep x 11” High
M4145 Dimensions - Cabinet Sizes 5” Deep x 20” High
• Front In / Front Out air pattern
• 16 gauge steel housing powder coated with
textured beige finish.
• Tubular pre-wired wireway with 40 Amp
capacity.
• Connectionboxes for right or left handwiring
with combination 1/2”-3/4” knockouts at
back and bottom.
• Steel heating element with steel fins.
• Linear limit thermal overload with automatic
reset.
•Made in U.S.A.
• Recess trim frame included.
• Custom colors available, consult factory.
Note: Not for residential applications.
Note: Products listed in this section are custom built and subject to 100% cancellation/restocking charges.
Note: Please see page 60 for custom color availability - add 10% to net heater cost.
LENGTH
(IN.)
WT.
(LBS)
WATTS per FOOT
AVAILABLE
VOLTS AVAILABLE
PH
LIST
24
20
187
250
333
208
240
277
1
752
36
33
869
48
39
1008
60
49
1144
72
56
1272
LENGTH
(IN.)
WT.
(LBS)
WATTS per FOOT
AVAILABLE
VOLTS
AVAILABLE PH
LIST
LENGTH
(IN.)
WT.
(LBS)
WATTS per FOOT
AVAILABLE
VOLTS
AVAILABLE PH
LIST
24
45
187
250
333
208
240
277
810
24
49
750
208
240
277
927
36
53
986
36
60
1139
48
63
1
1195
48
71
1
1387
60
77
1453
60
87
1689
72
92
1747
72
106
2035
24
47
500
666
208
240
277
823
24
49
500
666
750
208
240
927
36
57
1058
36
60
1139
48
67
1
1292
48
71
3
1387
60
82
1564
60
87
1689
72
100
1901
72
106
2037
