3310 Series Fan Forced Wall Heater - With Summer Fan Switch
Standard Models
Accessories - All Models
• Powder coated 18 gauge steel front.
• Automatic reset thermal limit.
• Steel block fin element.
• Weight 22 lbs.
• Made in U.S.A.
• Vane axial fan blade: 600 RPM / 175 CFM.
• Grill dimensions:
15-3/8” Wide x 20-9/64” High.
• Rough in dimensions:
14-3/16” Wide x 19-15/16” High x 4” Deep.
• Units with dual wattage, factory wired to highest wattage.
• Wattage selectable at time of installation on some models.
Typical Specifications: Furnish and install Electric Forced Air Heaters where
specified. The heaters shall be constructed of a heavy gauge steel housing. The
rough-in dimensions are 14-3/16” Wide x 19-5/16” High x 4” Deep. The finish
shall be powder coated paint in ivory or white color. The units shall be available in
ratings from 750 through 4800 Watts. The heaters shall have a low speed 600 RPM
motor which drives a vane axial blower to deliver a quiet 175 CFM of down flow air. The heating element shall be
of the sealed block fin type with large, parallel steel fins for quick heat transfer. Unit shall have a standard thermal
overload cutoff for added safety, a fan switch for fan only operation, and is available with a single pole, or double pole
built-in thermostat, or no thermostat. The in-built thermostat shall be calibrated to provide a range of 0 degrees F. to
110 degrees F. All heaters shall be listed by ETL. The heating element shall be supplied with a manufacturer’s 1 year
limited warranty.
Features
Product Specifications
Note: Fan switch not available on 277V models. 277V models are available without a fan switch on previous page.
MODELS WITH IN-BUILT DOUBLE POLE THERMOSTAT (0º - 110ºF TEMPERATURE RANGE)
IVORY
WHITE
WATTS
MAX
BTU’s
VOLTS
AMPS
LIST
MFG CATALOG
NUMBER
MFG MODEL
NUMBER
MFG CATALOG
NUMBER
MFG MODEL
NUMBER
03260602
E3312T2SRP
03262002
E3312T2SRPW 1000
3413
120
8.3
529
03260702
E3313T2SRP
03262102
E3313T2SRPW
1500
5120
12.5
750
2560
6.25
03260802
F3316T2SRP
03262202
F3316T2SRPW 4000
13648
208
19.2
541
03260902
F3317T2SRP
03262302
F3317T2SRPW 4800
16380
23
554
03261202
HF3315T2SRP
03262602 HF3315T2SRPW
3000 / 2250
10240
240 / 208
12.5 / 10.8
541
1500 / 1125
5120
6.2 / 5.4
03261302
HF3316T2SRP
03262702 HF3316T2SRPW
4000 / 3000
13648
16.8 / 14.4
2000 / 1500
6826
8.3 / 7.2
03261402
H3317T2SRP
03262802
H3317T2SRPW 4800
16380
240
20.0
563
MODELS WITH IN-BUILT SINGLE POLE THERMOSTAT (0º - 110ºF TEMPERATURE RANGE)
03825702
E3312TSRP
03825902
E3312TSRPW 1000
3413
120
8.3
497
03796102
E3313TSRP
03840102
E3313TSRPW
1500
5120
12.5
750
2560
6.25
03777102
F3316TSRP
03840202
F3316TSRPW 4000
13648
208
19.2
506
03777802
F3317TSRP
03840302
F3317TSRPW 4800
16380
23
519
03776002
HF3315TSRP
03840702
HF3315TSRPW
3000 / 2250
10240
240 / 208
12.5 / 10.8
521
1500 / 1125
5120
6.2 / 5.4
03776902
HF3316TSRP
03840802
HF3316TSRPW
4000 / 3000
13648
16.8 / 14.4
2000 / 1500
6826
8.3 / 7.2
03777602
H3317TSRP
03840902
H3317TSRPW 4800
16380
240
20.0
528
International Models
----
----
03964802
M3315T2SRPWi
3360
11468
220
15.27
541
1680
5734
7.64
----
----
03964902
M3316T2SRPWi
4032
13761
18.33
2016
6881
9.16
IVORY
WHITE
DESCRIPTION
ACCESSORY TYPE
LIST
MFG CATALOG
NUMBER
MFG MODEL
NUMBER
MFG CATALOG
NUMBER
MFG MODEL
NUMBER
03778502
BOX3310
03778502
BOX3310
ADDITIONAL BACK CAN
Field Installed
108
03299502
3310EX33R
03299602
3310EX33WR SURFACE MOUNTING FRAME
93
SUFFIX D
DISCONNECT SWITCH
Factory Installed
118
