Exhaust Fan Accessories - Fan Guards
Rear Box Guard Bolt Together With Wire Guards
Features
• For IE, IED, EHB and EHD models
• 1/4" Smaller than the panel size of the fan
• Meets OSHA requirements
Standard Models
Rear Expanded Metal Box Guard
• For IE, IED, EHB and EHD models
• 1/4" Smaller than the panel size of the fan
• Meets OSHA requirements
Standard Models
Features
Spiral Front and Rear Guards
• For EHD models only
• Fits between motor and blade
• Rear guard installed at factory only
• Meets OSHA requirements
Standard Models
Features
Expanded Metal Front Guard
• For EHB, EHD, IE, & IED models
• 1” Larger than blade size
• Meets OSHA requirements
Standard Models
Features
Expanded metal guard
60”
Spiral Front
Spiral Rear
MFG MODEL NUMBER
FITS FAN SIZE
LIST
IBG-24
24”
916
IBG-30
30”
965
IBG-36
36”
1161
IBG-42
42”
1218
IBG-48
48”
1492
IBG-60
60”
2302
MFG MODEL NUMBER
FITS FAN SIZE
LIST
IBG-12
12”
562
IBG-16
16”
562
IBG-18
18”
622
IBG-20
20”
622
MFG MODEL NUMBER
TYPE
FITS FAN SIZE
LIST
SF-12
SPIRAL FRONT
12”
309
SF-16
16”
330
SF-18
18”
365
SF-20
20”
376
SF-24
24”
404
SR-12
SPIRAL REAR
12”
319
SR-16
16”
340
SR-18
18”
376
SR-20
20”
388
SR-24
24”
417
MFG MODEL NUMBER
FITS FAN SIZE
LIST
EMF-12
12”
368
EMF-16
16”
382
EMF-20
20”
403
EMF-24
24”
424
EMF-30
30”
536
EMF-36
36”
663
EMF-42
42”
698
EMF-48
48”
762
EMF-60
60”
1148
