35 / 57
35
A
B
C
Attic Fans
• 120V, 1-Phase, 2-Speed motors
• Shutters automatically open when fan is turned on and
close tightly when fan is turned off
• Made in U.S.A.
Features
Belt Drive Wholehouse Fans
Standard Models
NOTE: Belt Drive Fan with “No Joist Cut” Shutter.
Ceiling Shutters
Control Options
“Joist out style” (For replacement only)
• 120V motor / 1-Phase
• Automatic adjustable thermostat (90°-130°F)
• Partially assembled (mounting tabs must be assembled)
• 15” diameter x 6” depth
• 4 mounting tabs on 16” centers
Gable Exhaust Fan
Features
Standard Models
Power Attic Mount Dome Ventilator
• 120V Motor / 1-Phase
• Automatic thermostat (90°-130°F)
• Insect and bird screen installed
• Powder coated metal dome and base
Features
Standard Models
Fan Dimensions
Note: Photograph is a representation of stocked models.
Actual model may vary in appearance.
MFG CATALOG
NUMBER
MFG MODEL
NUMBER
DESCRIPTION
CFM .03 SP ATTIC SIZE/ ST. FT.
WT.
(LBS)
LIST
08663702
GV-405-2B
Gable Mount Ventilator
1300
average/2000
11
123
08665202
AGD-1416B
Aluminum Damper for GV-405-2
----
----
3
71
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
FIT HOLE
SIZE (I.D.)
OUTSIDE
SIZE (O.D.)
FAN
SIZE
WT.
(LBS)
LIST
07944802 CS-10-W 26X26
28X28
24”
8
142
07944602 CS-13-W 32X34
34X36
30”
10
149
07945302 CS-14-W 34X34
36X36
30”
10
155
07944702 CS-18-W 32X43
34X45
36”
11
169
07945202 CS-19-W 34X43
36X45
36”
11
183
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
DESCRIPTION
WT.
(LBS)
LIST
07927002 2-SW
2 Speed wall switch & plate
1 41
05000802 1A22-7 SP Close on rise (Attic Thermostat) (80°-130°F)
1 48
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
SIZE SPEED MOTOR
HP
CFM @ .1
IN. H2O
PRESSURE
DROP w/
SHUTTER
FAN
SPEED
RPM
FAN
MOUNTING
DIMENSIONS
(IN)
EXHAUST
SQ. FT.
REQ’D
AMPS WT.
(LBS)
LIST
A B C
07936202 BD24-2-WHS 24” 2
1/3 4500/2700 612/410 28 29.5 14.5 7
5.7/4.8 40
774
07936302 BD30-2-WHS 30” 2
1/3 7600/5800 520/350 34 35.5 14.5 9
6.9/5.5 50
831
07936402 BD36-2-WHS 36” 2
1/3 9675/6400 395/265 40 41.5 14.5 12 6.3/3.1 64
914
MFG CATALOG
NUMBER
MFG MODEL
NUMBER
DOME
COLOR SPEED CFM .03 SP VOLTS
HP
RPM ATTIC SIZE /
SQ. FT.
WT.
(LBS)
LIST
08664202
PDV-305-1MB-GY Gray
1
1080
120
1/12
1050 Average/1600 18
158
08664302
PDV-305-1MB-BR Brown
1
1080
120
1/12
1050 Average/1600 18
08664402
PDV-305-1MB-BLK Black
1
1080
120
1/12
1050 Average/1600 18
