Hazardous Location - Specific Features
48” Two Speed
36” Single or Three Speed
(EVAP36-1 or EVAP36-3) provides cooling up to
2500 sq. ft. area. 32 Gallon reservoir capacity.
(EVAP48-2) provides cooling up to 4,000 sq. ft. area. 40
Gallon reservoir capacity.
Features
15°F - 25°F OF EVAPORATIVE COOLING
- PLUS -
6°F - 8°F OF WIND CHILL COOLING
36” UNIT IS THIN ENOUGH TO FIT THROUGH A STANDARD DOOR.
Standard Models
FRONT
BACK
36” & 48” Portable Evaporative Coolers
EVAPORATIVE COOLING TEMPERATURE DROPS
AIR
RELATIVE HUMIDITY
TEMPERATURE
10%
30%
50%
80
o
-22
o
-16
o
-10
o
90
o
-25
o
-18
o
-12
o
100
o
-29
o
-21
o
-14
o
110
o
-32
o
-23
o
-15
o
• 36" and 48" non hazardous location models feature 3/4" garden hose connections for longer
operating times
• Durable polyethylene housing features leakproof, one piece construction
• Lowers temperatures 15-25 °F depending on climate conditions
• Heavy duty, polyolefin casters on evaporative coolers
• New 3 blade fan blade for quieter operation; 120V
• Manufactured in U.S.A. shipped completely assembled, ready to use
Hazardous Location - Standard Models
FRONT
CONTROL
• All switches, motors, and cord connections are sealed to
prevent sparking in combustible locations
• Shipped completely assembled, ready to use
• 120/240V operation
• Manufactured in U.S.A.
• Component Rating: Class 1A, Division D for Hazardous
Location
Hazardous Location - Standard Models
Patented
Patented
Patented
Patented
Replacement Media Pads
EVAP-Tank 50
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
MOTOR
HP
UNIT
AMPS
CFM
EFFECTIVE
SQ. FT.
INTERNAL
WATER
(Gallons)
DIMENSIONS
L x W x H
(Inches)
WT.
(LBS)
LIST
HIGH MED LOW
08748102
EVAP36-1
1/2
12.4
9600
2500
32
32 x 62 x 67 235
4372
08748202
EVAP36-3
1/2
11.5 9600 6600 4800
2500
32
32 x 62 x 67 245
4782
08748402
EVAP48-2
1
13.7 22000 ----
11000
4000
40
36 x 74 x 86 405
6776
08760102 EVAP-Tank 50
50 gallon portable water tank accessory
1725
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
MOTOR
HP
UNIT
AMPS
CFM
EFFECTIVE
SQ. FT.
INTERNAL
WATER
(Gallons)
DIMENSIONS
L x W x H
(Inches)
WT.
(LBS)
LIST
HIGH MED LOW
08748302 EVAP36-HAZ 1/2 13.4
9600
2500
32
32 x 62 x 67
330
14124
08748502 EVAP48-HAZ 1
18
20000
4000
40
36 x 74 x 86
460
17091
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
CORRESPONDING
EVAP UNITS
TOTAL PADS
NEEDED
PADS
INCLUDED
LIST
08768702
PADEVAP-Mini500
EVAP Mini-500
3
3
200
08768302
PADEVAP-Mini700
EVAP Mini-700
3
3
300
05398502
PADEVAP-16
EVAP 16-3
3
1
134
05398802
PADEVAP-36
EVAP 36-1/3 or Haz
5
1
160
05399002
PADEVAP-48
EVAP 48-2 or Haz
6
1
176
