Portable Utility Lights
Features
Standard Models
Lamp Specifications - LED & FL
FL-2
+
PED
Incandescent, Fluorescent, and LED Series
Individual Portable Light Components - Replacement Bulbs
• Chip resistant safety yellow & black powder coating finish for high visibility
and durability
• 15’ long 18/3 SJT, 120V cordset with NEMA 15-5 grounded plug
• Shade will swivel 300
o
horizontally and 210
o
vertically
• On/Off switch, bulb, and wire guard included on each light head
• Made in U.S.A. with domestic and foreign components
• Aluminum shade is 9-3/8” long with 7-3/4” diameter opening and will
swivel 300
o
horizontally and 210
o
vertically
• LED 1 & 2 models are designed with an acrylic lens cover over each of
the 12 single Watt LED emitters. Constructed with narrow 15° angle beam
generating 960 lumens per bulb.
• FL models include a 55W spiral fluorescent bulb and internal reflector for
maximum illumination at shorter distances.
• ETL C/US Listed for indoor & semi-protected outdoor use
Lamp Specifications - QH
• QH models include a 500 Watt quartz halogen bulb and
weatherproof die cast aluminum light head with impact resistant lens
• Each shade size is 9” wide x 7-1/4” high x 9-3/4” deep
• ETL C/US listed for indoor & semi-protected outdoor use
QH-2
+
TRI
LED-2
+
TRI
LED-37-2
+
CRT
QH-1
+
CLP
QH-1
+
MAG
QH-1
+
FLR
Lamp Specifications - LED-37
• Lexan housing
• Safety glass front lens cover
• NEMA 4 rated enclosure
• Can be used with dock arm, pedestal, cart, and tripod bases only.
• Push button on-off switch
• 15’ power cord
• Compliant with RoHS 2 Directive (2011/65/EU), that of which includes the
application exemptions outlined in Annex III of the directive.
*Can be used with pedestal, cart, and tripod mounts only
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
TYPE
DESCRIPTION TOTAL MAX
WATTS
# OF LIGHT
HEADS
WT.
(LBS)
LIST
04885402
LED-37-1*
LIGHTHEAD
LED
37
1
6
340
04885302
LED-37-2*
74
2
10
688
04873602
LED-1
LED
12
1
6
289
04873702
LED-2
24
2
9
644
04803002
FL-1
FLUORESCENT
55
1
5
206
04803402
FL-2
110
2
8
515
04802902
QH-1
QUARTZ HALOGEN
500
1
5
129
04803302
QH-2
1000
2
10
217
04802702
PED
MOUNT / BASE
PEDESTAL
----
----
31
284
04802802
CRT
CART
----
----
27
248
04802302
TRI
TRIPOD
----
----
9
99
04802602
FLR
FLOOR
----
----
4
80
04802402
CLP
CLAMP
----
----
2
44
04802502
MAG
MAGNET
----
----
3
53
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
DESCRIPTION
WATTS
USED WITH
WT.
(LBS)
LIST
04850502
SSE-55
Fluorescent Bulb
55
ALL FL Light heads
1
54
04708502
LED-12
LED Bulb
12
ALL LED Light heads
1
110
