HOW TO DESIGNATE A MODEL:
Unit Length (Inches)
24, 36, 48, 60, or 72
Total Wattage
Series Number
Cabinet Size
25=11”H x 4”D 45=20”H x 5”D
Voltage/Phase
F=208V, 1 Phase G=277V, 1 Phase
H=240V, 1 Phase J=208V, 3 Phase
K=240V, 3 Phase
Control Option
Blank=None
T or T2=Thermostat R, R2, or R9=Relay
(See control option chart)
M41 25 F 48 1000 T
4100 Series Recessed Commercial Wall Convector
M4125 Dimensions - Cabinet Sizes 4” Deep x 11” High
M4145 Dimensions - Cabinet Sizes 5” Deep x 20” High
• Front In / Front Out air pattern
• 16 gauge steel housing powder coated with
textured beige finish.
• Tubular pre-wired wireway with 40 Amp
capacity.
• Connectionboxes for right or left handwiring
with combination 1/2”-3/4” knockouts at
back and bottom.
• Steel heating element with steel fins.
• Linear limit thermal overload with automatic
reset.
•Made in U.S.A.
• Recess trim frame included.
• Custom colors available, consult factory.
Note: Not for residential applications.
Note: Products listed in this section are custom built and subject to 100% cancellation/restocking charges.
LENGTH
(IN.)
WT.
(LBS)
WATTS per FOOT
AVAILABLE
VOLTS AVAILABLE
PH
24
20
187
250
333
208
240
277
1
36
33
48
39
60
49
72
56
LENGTH
(IN.)
WT.
(LBS)
WATTS per FOOT
AVAILABLE
VOLTS
AVAILABLE PH LENGTH
(IN.)
WT.
(LBS)
WATTS per FOOT
AVAILABLE
VOLTS
AVAILABLE PH
24
45
187
250
333
208
240
277
24
49
750
208
240
277
36
53
36
60
48
63
1
48
71
1
60
77
60
87
72
92
72
106
24
47
500
666
208
240
277
24
49
500
666
750
208
240
36
57
36
60
48
67
1
48
71
3
60
82
60
87
72
100
72
106
