CVX Series Radiant Cove Ceiling Heater
Cove Heaters have a subtly contoured concave surface with a saw-tooth profile. The concave parabolic face plate
performs a two-fold function: (1) it focuses the infrared rays and (2) directs the heat downward along cold perimeters
and toward the center of the room. The sawtooth surface design increases the radiating surface area by 45%, thereby
increasing the comfort level of the room faster and insuring more rapid recovery from heat losses.
Furnish and install Electric Cove Heaters where specified. The heaters shall be constructed of .096” thick Aluminum.
The heater surface shall be concave in contour and saw-tooth in profile. The finish shall be of powder coat white finish.
The heaters shall be available in ratings from 450 through 1250 Watts, at 120, 240, 208 and 277 Volts. The heating
element shall be of Nichrome wire, embedded in Magnesium Oxide powder, enclosed and sealed in Aluminum metal
tubing. The heater shall be listed by ETL and the elements shall be supplied with a one year limited warranty.
Made in U.S.A.
Product Specifications
Product Description
Accessories & Dimensions
* Order 2 for units up to 72”
Order 3 for units over 72”
Standard Models
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
WATTS BTU's AMPS VOLTS LENGTH WT.
(LBS)
04575802 CV4512X 450
1536
4
120
42”
7
04575902 CV45X 450
2
240
04576002 CV45YX 450
2.0
208
04576102 CV4527X 450
2
277
04576202 CV6012X 600
2048
5.0
120
60”
10
04576302 CV60X 600
3
240
04576402 CV60YX 600
3
208
04576502 CV6027X 600
2
277
04576602 CV7512X 750
2560
6
120
72”
13
04576702 CV75X 750
3
240
04576802 CV75YX 750
3.6
208
04576902 CV7527X 750
3
277
04577002 CV9012X 900
3072
8
120
84”
14
04577102 CV90X 900
4
240
04577202 CV90YX 900
4
208
04577302 CV9027X 900
3
277
04577402 CV10012X 1000
3413
8
120
96”
17
04577502 CV100X 1000
4
240
04577602 CV100YX 1000
5
208
04577702 CV10027X 1000
4
277
04577802 CV11012X 1100
3754
9
120
108”
19
04577902 CV110X 1100
5
240
04578002 CV110YX 1100
5
208
04578102 CV11027X 1100
4.0
277
04578202 CV12512X 1250
4266
10
120
120”
21
04578302 CV125X 1250
5
240
04578402 CV125YX 1250
6.0
208
04578502 CV12527X 1250
5
277
International Models
04711902 CV4522Xi
450 1536 2.0
220
42”
7
04712002 CV45Xi
1.9
240
04712102 CV6022Xi
600 2048 2.7
220
60”
10
04712202 CV60Xi
2.5
240
04712302 CV7522Xi
750 2560 3.4
220
72”
13
04712402 CV75Xi
3.1
240
04712502 CV9022Xi
900 3072 4.1
220
84”
14
04712602 CV90Xi
3.8
240
04712702 CV10022Xi
1000 3413 4.5
220
96”
17
04712802 CV100Xi
4.2
240
04712902 CV11022Xi
1100 3754 5.0
220
108”
19
04713002 CV110Xi
4.6
240
04713102 CV12522Xi
1250 4266 5.7
220
120”
21
04713202 CV125Xi
5.2
240
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
DESCRIPTION WT.
(LBS)
04579202 CVCBX Ceiling Bracket*
1/2
04578602 CVB42X 42” Blank Section
6
04578702 CVB60X 60” Blank Section
8
04578802 CVB84X 84” Blank Section
12
04579102 CVSP Aerosol Touch-up Paint
1
