3700 Series Architectural Style Electric Baseboard Heater
Standard Models
Product Specifications
Note: Refer to 3900 Series for product dimension specifications.
Manufactured in U.S.A.
Available in white or brown with stainless steel heating element and
aluminum fins.
Powder coated 12 gauge heavy duty extruded Aluminum housing
construction with junction boxes located on each end of the unit.
An automatic thermal linear limit is used along the entire heated length
of the unit.
Wire guard extends along the entire outlet area of the baseboard.
Special colors available, consult factory.
The entire heater casing
shall be constructed of
6063 extruded Aluminum.
Minimum thickness of .100”
(12 gauge) Aluminum shall
be acceptable. Outlet grill
shall cover entire length of
air discharge opening and be
constructed of steel. All casing
and grill construction shall
be painted with high quality
durable powder coated paint.
The heating element
shall be high quality nichrome
wire encased in Magnesium
Oxide and sealed in a stainless
steel tube.
Linear
automatic
thermal limit shall extend the
entire heater length of element
and protect heater in case of an
over-temperature condition.
Optional
controls
shall be mounted in junction
box enclosures at either end
of heater. Optional integral
thermostat shall be located in
junction box with adjustment
knob or for tamper-proof
operation. Optional disconnect
switch shall be mounted
in junction box. Optional
120 Volt or air conditioning
receptacle shall be mounted in
junction box.
Optional installation
accessories shall include
inside and outside corner
sections for complete wall
perimeter fit. Profile of corners
and grill shall have appearance
of heat sections for continuous
architectural design. Corner
accessories and heater sections
shall be secured by alignment
pins for easy alignment of
multiple heater applications.
STANDARD WHITE COMMERCIAL BROWN
WATTS BTU’s VOLTS AMPS
HEATER
LENGTH
(IN.)
WT.
(LBS.)
UPC
686334 MODEL UPC
686334 MODEL
116008 E3703-024 116435 E3703-024B 375
1275
120
3.1
24 14
116015 F3703-024 116442 F3703-024B 375
1275
208
1.8
116022 H3703-024 116459 H3703-024B 375 / 281 1275 / 955 240 / 208 1.6/1.4
116039 G3703-024 116466 G3703-024B 375 / 281 1275 / 955 277 / 240 1.6/1.2
116046 E3705-028 116473 E3705-028B 500
1706
120
4.2
28 16
116053 F3705-028 116480 F3705-028B 500
1706
208
2.4
116060 H3705-028 116497 H3705-028B 500 / 375 1706 / 1275 240 / 208 2.1/1.8
116077 G3705-028 116503 G3705-028B 500 / 375 1706 / 1275 277 / 240 1.8/1.6
116084 E3706-036 116510 E3706-036B 600
2040
120
5
36 22
116091 F3706-036 116527 F3706-036B 600
2040
208
2.9
116107 H3706-036 116534 H3706-036B 600 / 450 2040 / 1530 240 / 208 2.5/2.2
116114 G3706-036 116541 G3706-036B 600 / 450 2040 / 1530 277 / 240 2.2/1.9
116121 E3707-040 116558 E3707-040B 750
2550
120
6.3
40 27
116138 F3707-040 116565 F3707-040B 750
2550
208
3.6
116145 H3707-040 116572 H3707-040B 750 / 563 2550 / 1914 240 / 208 3.1/2.7
116152 G3707-040 116589 G3707-040B 750 / 563 2550 / 1914 277 / 240 2.7.2.6
116169 E3710-048 116596 E3710-048B 1000
3413
120
8.3
48 31
116176 F3710-048 116602 F3710-048B 1000
3413
208
4.8
116183 H3710-048 116619 H3710-048B 1000 / 750 3413 / 2550 240 / 208 4.2/3.6
116190 G3710-048 116626 G3710-048B 1000 / 750 3413 / 2550 277 / 240 3.6/3.1
116206 G3707-048 116633 G3707-048B 750
2550
277
3.4
116213 E3712-060 116640 E3712-060B 1250
4250
120
10.4
60 33
116220 F3712-060 116657 F3712-060B 1250
4250
208
6
116237 H3712-060 116664 H3712-060B 1250 / 938 4250 / 3189 240 / 208 5.2/4.5
116244 G3712-060 116671 G3712-060B 1250 / 938 4250 / 3189 277 / 240 4.5/3.9
116251 G3709-060 116688 G3709-060B 938
3189
277
3.4
116268 E3715-072 116695 E3715-072B 1500
5100
120
12.5
72 41
116275 F3715-072 116701 F3715-072B 1500
5100
208
7.2
116282 H3715-072 116718 H3715-072B 1500 / 1125 5100 / 3825 240 / 208 6.3/4.7
116299 G3715-072 116725 G3715-072B 1500 / 1125 5100 / 3825 277 / 240 5.4/4.7
116305 G3711-072 116732 G3711-072B 1125
3825
277
4.1
116312 F3717-084 116749 F3717-084B 1750
5950
208
8.4
84 49
116329 H3717-084 116756 H3717-084B 1750 / 1313 5950 / 4464 240 / 208 7.3/6.3
116336 G3717-084 116763 G3717-084B 1750 / 1313 5950 / 4464 277 / 240 6.3/5.5
116343 G3713-084 116770 G3713-084B 1313
4464
277
4.7
116350 F3720-096 116787 F3720-096B 2000
6826
208
9.6
96 58
116367 H3720-096 116794 H3720-096B 2000 / 1500 6826 / 5100 240 / 208 8.3/7.2
116374 G3720-096 116800 G3720-096B 2000 / 1500 6826 / 5100 277 / 240 7.2/6.3
116381 G3715-096 116817 G3715-096B 1500
5100
277
5.4
116398 F3725-120 116824 F3725-120B 2500
8532
208
12
120 67
116404 H3725-120 116831 H3725-120B 2500 / 1875 8532 / 6375 240 / 208 10.4/9.0
116411 G3725-120 116848 G3725-120B 2500 / 1875 8532 / 6375 277 / 240 9.0/7.8
116428 G3718-120 116855 G3718-120B 1875
6375
277
6.8
