• Units have white powder coat finish.
Approved for horizontal mounting - right or left discharge.
Drywall depth embossments on back can.
Powder coated 18 gauge steel front.
Manual reset thermal limit.
Finned tubular steel element.
Weight 6 lbs.
Propeller style fan blade: 2200 RPM / 70 CFM.
• Optional field installed In-Built thermostat.
Rough in dimensions: 9-1/4” Wide, 12-1/8” High, 3-5/8” Deep.
Grill dimensions: 9-25/32” Wide, 13” High.
3200 Series Midsized Fan Forced Wall Heater - With Wall Box
“TWO WIRE INSTALLATION”
Features
Standard Models
Accessories
Manufactured in U.S.A.
FIELD INSTALLED COMPONENTS
UPC
MODEL
DESCRIPTION
686334
383646
32T1 Single Pole thermostat with positive off for
120V units 50
o
- 90
o
F
383653
32T2 Double Pole thermostat with positive off for
240/208V units 50
o
- 90
o
F
SURFACE MOUNTED EXTENDERS & FRAMES
WHITE
DESCRIPTION
UPC
686334
MODEL
996976 303EX8RW
1” EXTENDER
996969 303EX16RW
2” EXTENDER
996952 303EX32RW 4” SURFACE MOUNT FRAME
UPC
MODEL
VOLTS
WATTS
MAX
AMPS
686334
BTU’S
BUILT-IN DOUBLE POLE (POSITIVE OFF) THERMOSTAT 50° - 90° F RANGE
383462
F3220T2RPW
208
2000
6826
9.6
383479
H3275T2RPW
240
750
2560
3.1
383486
HF3210T2RPW
240/208
1000 / 750
3413 / 2560
4.2 / 3.6
383493
HF3215T2RPW
1500 / 1125
5120 / 3840
6.3 / 5.4
383509
HF3220T2RPW
2000 / 1500
6826 / 5120
8.3 / 7.2
383516
HF3222T2RPW
2250 / 1688
7680 / 5762
9.4 / 8.1
International Models - BUILT-IN DOUBLE POLE (POSITIVE OFF) THERMOSTAT 50° - 90° F RANGE
396387
M3210T2RPWi
220
840
2867
3.8
396394
M3215T2RPWi
1260
4300
5.7
396400
M3220T2RPWi
1680
5734
7.6
396417
M3222T2RPWi
1890
6451
8.6
Standard Models - BUILT-IN SINGLE POLE (POSITIVE OFF) THERMOSTAT 50° - 90° F RANGE
383523
E3275TRPW
120
750
2560
6.25
383530
E3210TRPW
1000
3413
8.33
383547
E3215TRPW
1500
5120
12.5
NO BUILT-IN THERMOSTAT
383554
E3275RPW
120
750
2560
6.25
383561
E3210RPW
1000
3413
8.33
383578
E3215RPW
1500
5120
12.5
383585
F3220RPW
208
2000
6826
9.6
383592
H3275RPW
240
750
2560
3.1
383608
HF3210RPW
240/208
1000 / 750
3413 / 2560
4.2 / 3.6
383615
HF3215RPW
1500 / 1125
5120 / 3840
6.3 / 5.4
383622
HF3220RPW
2000 / 1500
6826 / 5120
8.3 / 7.2
383639
HF3222RPW
2250 / 1688
7680 / 5762
9.4 / 8.1
