4800 Series Register Style Fan Forced Wall Heater - With Wall Box
Features
• Units have white powder coat finish.
Powder coated 20 gauge steel front.
Manual reset thermal limit.
Finned tubular steel element.
Propeller style fan blade - 2200 RPM / 70 CFM.
Weight 9 lbs.
Rough in dimensions: 14-1/2”Wide x 7-1/8” High x 3-1/2” Deep.
Grill dimensions:
16-3/4”Wide x 7-5/8” High.
Unit not approved for ceiling mount applications.
Left discharge only.
Accessories
Standard Models
Manufactured in U.S.A.
UPC
MODEL
VOLTS
WATTS
MAX
AMPS
686334
BTU’S
DOUBLE POLE IN-BUILT THERMOSTAT (40º - 110º F TEMPERATURE RANGE)
328159
F4820T2RPW
208
2000
6826
9.6
328166
HF4875T2RPW
240/208
750 / 562
2560 / 1920
3.1 / 2.7
328173
HF4810T2RPW
1000 / 750
3413 / 2560
4.2 / 3.6
328180
HF4815T2RPW
1500 / 1125
5120 / 3840
6.3 / 5.4
328197
HF4820T2RPW
2000 / 1500
6826 / 5120
8.3 / 7.2
SINGLE POLE IN-BUILT THERMOSTAT (50º - 90º F TEMPERATURE RANGE)
328203
E4875TRPW
120
750
2560
6.25
328210
E4810TRPW
1000
3413
8.33
328227
E4815TRPW
1500
5120
12.5
328234
F4820TRPW
208
2000
6826
9.6
NO IN-BUILT THERMOSTAT
328241
E4875RPW
120
750
2560
6.25
328258
E4810RPW
1000
3413
8.33
328265
E4815RPW
1500
5120
12.5
328272
F4820RPW
208
2000
6826
9.6
328289
HF4875RPW
240/208
750 / 562
2560 / 1920
3.1 / 2.7
328296
HF4810RPW
1000 / 750
3413 / 2560
4.2 / 3.6
328302
HF4815RPW
1500 / 1125
5120 / 3840
6.3 / 5.4
328319
HF4820RPW
2000 / 1500
6826 / 5120
8.3 / 7.2
UPC#
686334
MODEL
DESCRIPTION
WT. LBS.
328456
4300EX8W
1” SEMI RECESSING EXTENDER
2
328463
4300EX16W
2” SEMI RECESSING EXTENDER
3
328470
4300EX32W
4” SURFACE MOUNTING FRAME
4
328487
4300PW
WALL PLATE ADAPTOR (OD 21.5” x 12.25”)
1
329774
43T
SINGLE POLE THERMOSTAT 50
O
- 90
O
F
1
329798
48T2
DOUBLE POLE THERMOSTAT 50
O
- 90
O
F
1
