DBTS Series Draft Barrier Heaters
Features
Bottom air intake.
Maximum watts per foot: 300.
Dimensions: Depth 2-5/8'” x Height 4" Length 2’ to 10'.
14 gauge Aluminum housing.
Voltages: 120V / 208V / 240V / 277V - 1 Phase
No controls can be added without adding a control section and
extended enclosure.
Standard Models
Manufactured in U.S.A.
Accessories
Not suitable for residential applications. 150 watts
per foot maximum. Built to order: consult factory
for lead time.
MODEL
LENGTH
HEATER
DBTS-2
2’
DBTS-3
3’
DBTS-4
4’
DBTS-5
5’
DBTS-6
6’
DBTS-7
7’
DBTS-8
8’
DBTS-9
9’
DBTS-10
10’
MODEL
DESCRIPTION
DBTS IC
Inside Corner Section 90° - 180°
DBTS OC
Outside Corner Section 180° - 270° - 6” longest side
DBTS ECR
Right Hand End Cap
DBTS ECL
Left Hand End Cap
DBTS IECR
Inside Fitting Right End Cap
DBTS IECL
Inside Fitting Left End Cap
DBTS WT
Wall Trim 2” - 6”
DBTS SP
Splice Plate 1 1/2”
DBTS MF
Mullion Front up to 1’
Note on order
1/2” Conduit Raceway
Mesh 1/4” Wire Mesh under grill
Pedestals - specify 2” or 3”
MODEL
LENGTH
BLANK
SECTION
DBTS-100BS
1’
DBTS-200BS
2’
DBTS-300BS
3’
DBTS-400BS
4’
DBTS-500BS
5’
DBTS-600BS
6’
DBTS-700BS
7’
DBTS-800BS
8’
DBTS-900BS
9’
DBTS-1000BS
10’
