RPH Series Outdoor Rated Stainless Steel Electric Infrared Heater
MM Series “Mitey Midget” Electric Infrared Heater
FFH Series Electric Utility Infrared Heater
MountingPlate (provided)
on top center allows heater
to be mounted parallel or
angled using a standard
pipe nipple and box cover
(supplied by installer)
Instant, high-intensity radiant heat, with 30° symmetric heat pattern.
Listed for indoor spot heating and for outdoor unprotected applications.
Specialized Ruby “Red” Quartz Lamp infrared heating element for glare reduction.
• Stainless Steel housing with Coilzak Aluminum reflector for good reflectivity & corrosion
resistance.
Heating element and mounting plate included.
Dimensions: 24” x 5-3/8” x 4-1/2.”
Mounting Clearances
Recommended Mounting Height
6” from ceiling
24” from vertical surface
72” from face of heater to combustible surface
RPH-208
8’-12’
RPH-240
8’-12’
All MM-13A through MM-46A models are ETL Listed for use with Quartz Lamps Only!
Mounting Clearances
24” from ceiling & from vertical surface
24” from face of heater to combustible surface
36” from another heater
Instant, high-intensity radiant heat, with 60° symmetric heat pattern.
MM heaters excel as people-heaters in areas requiring a linear, compact & concentrated heat source.
Listed for indoor industrial and commercial comfort heat applications.
Heavy duty Aluminum extrusion with a bright
Aluminum insert for maximum reflectivity.
Anodized Aluminum housing, (0.62” thick).
Heat Element Sold Separately.
Dimensions: 3.750” Wide x 3.380” High.
Mounting Clearances
3” from ceiling
24” from vertical surface
72” from floor
FFH-512A
FFH-912B
Both FFH Series Heaters are excellent for Farrowing & Finishing applications.
Both units feature an 8 ft. 18/3 grounded cordset to plug into any 120V service.
• Gold anodized Aluminum reflectors, with a 90° symmetrical reflector pattern.
• Compact housing design, with the following housing finish:
FFH-512A: Gold Anodized Finish
FFH-912B: Brown Enamel Finish
Quartz Tubes Heat Element(s), Wire Guard & (2) 4’ ft. Jack Chains are included.
FFH-912B Only: Offers (2) On/Off
toggle switches to operate heating
elements independently.
Listed for indoor industrial and
commercial comfort heat
Manufactured in U.S.A.
Manufactured in U.S.A.
Manufactured in U.S.A.
SIZING CHART - FFH SERIES
MOUNTING
HEIGHT
Heater
Model LENGTH WIDTH COVERAGE
(Sq. Ft.)
WATTS
/ Sq. Ft.
6’
FFH-512A 7
6
42
13.1
FFH-912B 6
7
42
21.4
7’
FFH-512A 8
7
56
9.8
FFH-912B 7
8
56
16.1
8’
FFH-512A 9
8
72
7.6
FFH-912B 8
9
72
12.5
UPC
686334
MODEL
MAX
WATTS
MAX
BTU'S VOLTS PH UNIT
LENGTH WT. (LBS.)
Optional Wireguards
UPC
686334
MODEL
444019
MM-13A
500
1707
120
1
13"
3
443906
MMWG-13
442763
MM-18A 750 / 1000
3413 208-240 1
18"
4
443913
MMWG-18
449540
MM-24A 900 / 1600
5461 208-277 1
24"
5
441896
MMWG-24
442725
MM-33A
2500
8533
480
1
33"
6
443920
MMWG-33
442039
MM-46A 3000 / 3800 12457 480-600 1
46"
7
442046
MMWG-46
UPC#
686334
MODEL
WATTS BTU’S VOLTS PHASE AMPS REPLACEMENT
QUARTZ LAMP
WT.
(LBS.)
Optional Wireguard
UPC# 686334 MODEL
884501 RPH-208-A 1600 5,461 208
1
7.7
632-1620
5
880992
RPHWG
884518 RPH-240-A 1600 5,461 240
1
6.7
632-1624
5
UPC#
686334 MODEL WATTS BTU’S VOLTS PHASE AMPS REPLACEMENT
QUARTZ TUBE
WT.
(LBS.)
Dimensions (in.)
Length Width Height
883894 FFH-512A 550 1877 120
1
5
671-3492
4
22
5
3
882781 FFH-912B 450/900 3072 120
1
8
671-3454
4
17
6
4
