OCH Series Outdoor / Indoor Rated Quartz Electric Infrared Heater
Features
Frosted Quartz Tube heating element (included)
Listed for suspended, totally exposed (outdoor) and indoor
spot heating applications
• Finish: High-temp brown powder coated finish or corrosion
resistant stainless steel 24 gauge housing
60° Symmetric Heat Pattern
• Gold anodized Aluminum reflector and end caps
• Painted models are direct wire, unless specified and are
supplied with 6” lead wires for field connection in the
internal wiring compartment. These models are available
with a factory installed 6’ cord set. The 208V model must
have a field supplied plug.
Stainless steel models include an electrical enclosure
assembled to the end of the heater housing and (2) 6” long
lead wires for direct field connection.
Two 2’ ft. long mounting chains and four S-Hooks included
The OCH-Series can be surfaced mounted using the supplied
mounting brackets which allow up to a 45° horizontal tilt
adjustment.
Product Models
Product Accessories
Manufactured in U.S.A.
Heats solid objects, not the air!
UPC#
686334
MODEL
DESCRIPTION
FOR USE WITH
WT.
(LBS.)
480888
OCHWG-46
Stainless Steel Wire Guards
OCH-46 Series Models
2
480895
OCHWG-57
OCH-57 Series Models
2
881128
VMB-41-SS
Wall Mtg. Brackets (2)
ALL OCH Models
12
445948
VHC-15
Variable Heat Controller
ALL OCH Models
3
485357
VHC-32
Variable Heat Controller
ALL OCH Models
3
FINISH - BROWN
FINISH - STAINLESS STEEL
CONNECTION
TYPE WATTS BTU’S VOLTS AMPS
Qtz. Tube
Repl.
Element
WT.
(LBS.)
Includes Electrical Enclosure
UPC#
686334
MODEL
UPC#
686334
MODEL
480444
OCH-46-120VE
480529
OCH-46-120V-SSE
Hard Wire
1500 5120 120 12.5 671-3784
10
480451
OCH-46-208VE
480536
OCH-46-208V-SSE
2000 6826 208 9.6 671-5061
480468
OCH-46-240VE
480543
OCH-46-240V-SSE
2000 6826 240 8.3 671-3785
480475
OCH-46-277VE
480550
OCH-46-277V-SSE
2000 6826 277 7.2 671-5018
480499
OCH-57-208VE
480574
OCH-57-208V-SSE
3000 10239 208 14.4 671-5060
12
480482
OCH-57-240VE
480567
OCH-57-240V-SSE
3000 10239 240 12.5 671-3786
480505
OCH-57-277VE
480581
OCH-57-277V-SSE
3000 10239 277 10.8 671-5059
480512
OCH-57-480VE
480598
OCH-57-480V-SSE
2250 7679 480 4.7 671-5058
485975
OCH-46-120VCE
---
---
Corded
1500 5120 120 12.5 671-3784 11
485982
OCH-57-208VCE
---
---
2000 6826 208 9.6 671-5061
13
485999
OCH-57-240VCE
---
---
2000 6826 240 8.3 671-3785
