THSS Series Mul-T-Mount Electric Infrared Heater
TH & THSS Series Product Accessories
3 Lamp Mul-T-Mount Series
Stainless Steel Housing With 3 Clear Quartz Lamps Included
NOTE:
600-Volt Models also available, contact factory
for more information.
Asymmetrical pattern units are also available
for 30° & 60°
Manufactured in U.S.A.
UPC#
686334
MODEL
KW BTU’S VOLTS Reflector
Pattern
Replacement
Elements
WT.
(Lbs.)
443678 223-30-THSS-208V
4.8 16382
208
30°
Symmetrical
63016209
25
443685 223-30-THSS-240V
240
63016249
443692 223-30-THSS-277V
277
63016279
481588 223-30-THSS-480V
480
63016489
443289 223-60-THSS-208V
208
60°
Symmetrical
63016209
443739 223-60-THSS-240V
240
63016249
443746 223-60-THSS-277V
277
63016279
481595 223-60-THSS-480V
480
63016489
443784 223-90-THSS-208V
208
90°
Symmetrical
63016209
443791 223-90-THSS-240V
240
63016249
443807 223-90-THSS-277V
277
63016279
481601 223-90-THSS-480V
480
63016489
481236 343-30-THSS-208V
7.5 25298
208
30°
Symmetrical
63025209
33
481243 343-30-THSS-240V
240
63025249
811439 343-30-THSS-480V
480
63025489
481267 343-60-THSS-208V
208
60°
Symmetrical
63025209
481274 343-60-THSS-240V
240
63025249
811637 343-60-THSS-480V
480
63025489
481298 343-90-THSS-208V
208
90°
Symmetrical
63025209
481304 343-90-THSS-240V
240
63025249
811835 343-90-THSS-480V
480
63025489
810531 463-30-THSS-480V
37372 480
30° Sym.
63036489
41
810739 463-60-THSS-480V 10.95
60° Sym.
63036489
810937 463-90-THSS-480V
90° Sym.
63036489
UPC
MODEL
DESCRIPTION
FOR USE WITH WT.
(LBS.)
686334
881128
VMB-41-SS
Wall Mounting Brackets (2)
All Mul-T-Mount Models
12
851152
CHWG-222
Stainless Steel Wire Guards
222 Series
2
851145
CHWG-342
342 Series
851626
CHWG-462
462 Series
854368
CHWG-223
223 Series
854351
CHWG-343
343 Series
854344
CHWG-463
463 Series
Recessed Mounting Frames (UL)
Ceiling Cutout (in.)
Frame Size (in.)
441995
RMF-222-SS-A
27 x 17-7/8
29-1/8 x 20
222 Series Stainless
6
449441
RMF-222-A
27 x 17-7/8
29-1/8 x 20
222 Series Painted
442077
RMF-342-SS-A
36 x 17-7/8
38-1/8 x 20
342 Series Stainless
9
441872
RMF-342-A
36 x 17-7/8
38-1/8 x 20
342 Series Painted
442107
RMF-462-SS-A
49 x 17-7/8
51-1/8 x 20
462 Series Stainless
11
449458
RMF-462-A
49 x 17-7/8
51-1/8 x 20
462 Series Painted
881104
RMF-223-SS
32 x 29-3/8
34-1/8 x 31-1/2 223 Series Stainless
15
881135
RMF-343-SS
41 x 29-3/8
43-1/8 x 31-1/2 343 Series Stainless
18
881111
RMF-463-SS
54 x 29-3/8
56-1/8 x 31-1/2 463 Series Stainless
20
440783
31939009
Red Vycor Sleeves
All 1600W Qtz. Lamp
2
440738
31940009
Reduces Quartz Lamp
All 2500W Qtz. Lamp
440745
31941009
Brightness by 90%
All 3650W Qtz. Lamp
446150
632-1620
Red Quartz Lamps; 1.6kw, 208v
222,223 & RPH Series
2
446167
632-1624
Red Quartz Lamps; 1.6kw, 240v
446228
632-2548
Red Quartz Lamps; 2.5kw, 480v
342 & 343 Series
