HOW TO DESIGNATE A MODEL:

Series Number

Element KW

3KW through 50KW

See model chart for KW options.

Element Voltage

F = 208V H = 240V G = 277V P = 480V

Phase

1 = Single Phase 3 = Three Phase

Control System

Blank = None

T = Unit Thermostat

SSR = SSR Control

Motor Voltage

E = 120 G = 277 P = 480

Heater Stages

Blank = One 2 = Two

F 3 E 72 15 2 T

7200 Series Plenum Heater

Product Specifications

• 20 gauge galvanized cabinet.

• Variable speed motor, factory set at maximum. Motor speed

can be field adjusted to increase heat rise.

• Acoustically insulated with 1” fiberglass.

• Access panels on both sides of cabinet.

• 24 Volt controls. / Disconnect switch

• Air flow switch.

• Terminal blocks.

• Single point connection.

• Dust tight control enclosure.

• Filter rack on inlet with throw away filter.

• Inlet and outlet screens and duct connection.

• Automatic primary limit control and secondary fuse link.

• Optional wall thermostat, unit thermostat or SSR control

which proportionally regulates heat output.

• Made in U.S.A.

Standard Models

MFG

CATALOG

NUMBER

MFG

MODEL

NUMBER

KW CFM

RANGE

VOLTS /

PHASE

TOTAL

AMPS for

MOTOR &

HEATER

STAGE MOTOR

VOLTAGE

FULL LOAD

AMPS for

MOTOR ONLY

MOTOR

H.P.

WT.

(LBS)

LIST

06176802 F1G7203

3

70-270

208/1

15.4

1

208

1

1/15

98

1716

06065602 H1G7203

240/1

13.5

240

1

06062401 G1G7203

277/1

11.83

277

1

06069002 F3G7203

208/3

9.32

208

1

1770

06177602 H3G7203

240/3

8.21

240

1

06176602 F1G7205

5

200-650

208/1

25.13

1

208

1.1

1/6

118

1770

06179502 H1G7205

240/1

21.93

240

1.1

06061602 G1G7205

277/1

19.15

277

1.1

06064202 F3G7205

208/3

14.97

1

208

1.1

1802

06179902 H3G7205

240/3

13.12

240

1.1

06065002 P3P7205

480/3

7.11

480

1.1

2119

06065502 F3E7210

10 500-1200

208/3

33.05

1

120

5.3

1/4

141

1889

06177302 H3G7210

240/3

25.75

240

1.7

06175802 P3G7210

480/3

13.72

277

1.7

2206

06065102 F3E7210-2

208/3

33.05

2

120

5.3

1977

05343902 H3G7210-2

240/3

25.75

240

1.7

06063402 P3P7210-2

480/3

13.72

480

1.7

2293

06086002 F3E7215

15 500-1200

208/3

46.93

1

120

5.3

1977

06088402 H3G7215

240/3

37.78

240

1.7

06060702 P3P7215

480/3

19.74

480

1.7

2293

06069402 F3E7215-2

208/3

46.93

2

120

5.3

2075

05344002 H3G7215-2

240/3

37.78

240

1.7

05345502 P3P7215-2

480/3

19.74

480

1.7

2392

06088302 F3E7220-2

20 750-1600

208/3

63.81

2

120

8.3

1/2

163

2458

05344102 H3G7220-2

240/3

50.61

240

2.5

06064902 P3P7220-2

480/3

26.55

480

2.5

2775

05344202 F3E7223-2 23 1300-2000

208/3

74.84

2

120

11

3/4

201

3058

06178802 H3G7223-2

240/3

59.63

240

4.3

05345602 P3P7225-2 25

480/3

34.37

480

4.3

3156

05344302 H3G7230-2 30 1800-2800

240/3

78.47

2

240

6.3

2 MOTORS @

1/2 H.P. EACH 278

4259

06068802 P3P7230-2

480/3

42.38

480

6.3

4532

05345702 P3P7235-2 35

480/3

48.39

480

6.3

4761

05345802 P3P7240-2 40

2000-3600

480/3

56.71

2

480

8.6

2 MOTORS @

3/4 H.P. EACH 319

5711

05345902 P3P7245-2 45

480/3

62.72

480

8.6

5820

06180802 P3P7250-2 50

480/3

68.74

480

8.6

6203
