Hotpod
®
Supplemental Duct Mounted Heating System
• Use to heat cold rooms or additions without upgrading central
system
• Fan only operation for increased cfm output for A/C cycles
• 6" 1000/500 Watt and 8" 1440/720 Watt models available
• Two stage operation
• 120V corded and hard wire models available
• 10' Cord length on corded models
• Zero clearance for all models
• All models include UT8003 low voltage thermostat
• Optional wireless thermostat
• Silent boot option available for rigid duct applications only.
• Made in U.S.A. with domestic and foreign components.
• Patented: Patent No. 8,285,127, 8,625,976, 8,787,738
HotPod - Features
Standard HotPod
®
Models
Multi-Pak Models - Includes 4 HotPod
®
Units
Note: Multi-Pak specifications (watts, volts, etc) are for each individual hotpod in the pack excluding weight.
6” Hotpod
8” Hotpod
*includes 1 HotPod display
Standard SilentBooster
®
Models
6” SilentBooster
®
8” SilentBooster
®
SilentBooster
®
- Features
• 120V corded and hardwire models available
• Adds 120 CFM Boost to duct heating or ventilation applications
• Can utilize optional TPI SilentBoot™ for whisper quiet operation in
rigid duct application.
• 14” of duct, 4’ from register is all that is needed for installation
• Optional wireless thermostat can be utilized to control SilentBooster
to increase room comfort
SilentBooster
®
Supplemental Duct Mounted Boosting System
Moisture Control System - Features
• 120V, 8” Ducted Booster Fan; De-humidistat included
• Includes all ductwork and outside damper / 6” to 8” adapters available
• Uses Heavy Duty booster fan to eliminate humidity from basements,
crawl spaces, or damp areas.
• Made in U.S.A. with foreign and domestic componets.
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
DESCRIPTION
WATTS VOLTS MIN.CIRC.
SIZE (AMP)
TEMP
RISE (F)
WT.
(LBS) RPM CFM NEMA
PLUG
DIMENSION
L x W x H (In.)
LIST
02900702 HP6-1000120-2T 6” INLET, HARDWIRE 1000/500 120
8.33
26
4 1500 130 NA 10 1/2 x 8 1/2 x 6
545
02900402 HP6-1000120-2CT 6” INLET, WITH CORD SET 1000/500 120
8.33
26
4 1500 130 5-15P 10 1/2 x 8 1/2 x 6
572
02900802 HP8-1440120-2T 8” INLET, HARDWIRE 1440/720 120
12.6
23
6 1500 210 NA 11 x 10 1/2 x 8
664
02900602 HP8-1440120-2CT 8” INLET, WITH CORD SET 1440/720 120
12.6
23
6 1500 210 5-15P 11 x 10 1/2 x 8
704
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
DESCRIPTION
WATTS VOLTS
MIN.CIRC.
SIZE
(AMP)
TEMP
RISE
(F)
WT.
LBS RPM CFM NEMA
PLUG
DIMENSION
L x W x H (In.)
LIST
02900302 HP6-1000120-2T 4 PACK 6” INLET, HARDWIRE 1000/500 120 8.33
26 16 1500 130 NA 10 1/2 x 17 x 12
2178
02901102 HP6-1000120-2CT 4 PACK 6” INLET, WITH CORD SET 1000/500 120 8.33
26 16 1500 130 5-15P 10 1/2 x 17 x 12
2284
02900502 HP8-1440120-2T 4 PACK 8” INLET, HARDWIRE 1440/720 120 12.6
23 25 1500 210 NA 10 1/2 x 20 x 16
2653
02901202 HP8-1440120-2CT 4 PACK 8” INLET, WITH CORD SET 1440/720 120 12.6
23 25 1500 210 5-15P 10 1/2 x 20 x 16
2814
02903302 HP6H-12PK* 12 PACK 6” INLET, HARDWIRE 1000/500 120 8.33
26 58 1500 130 NA 21 x 14 1/2 x 43
6532
02903402 HP6C-12PK* 12 PACK 6” INLET, WITH CORD SET 1000/500 120 8.33
26 58 1500 130 5-15P 21 x 14 1/2 x 43
6850
02903502 HP8H-12PK* 12 PACK 8” INLET, HARDWIRE 1440/720 120 12.6
23 82 1500 210 NA 27 1/4 x 14 1/2 x 52
7957
02903602 HP8C-12PK* 12 PACK 8” INLET, WITH CORD SET 1440/720 120 12.6
23 82 1500 210 5-15P 27 1/4 x 14 1/2 x 52
8441
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
DESCRIPTION
VOLTS MIN.CIRC.
SIZE (AMP)
WT.
(LBS) RPM CFM NEMA
PLUG
DIMENSION
L x W x H (In.)
LIST
02903702 SB6-120-T
6” SilentBooster (Hardwire)
120
15
4 1500 130 NA 10 1/2 x 8 1/2 x 6
239
02903802 SB6-120-CT
6” SilentBooster (w/Cord Set)
120
15
4 1500 130 5-15P 10 1/2 x 8 1/2 x 6
266
02903902 SB8-120-T
8”SilentBooster (Hardwire)
120
15
4 1500 210 NA 11 x 10 1/2 x 8
266
02904002 SB8-120-CT
8” SilentBooster (w/Cord Set)
120
15
4 1500 210 5-15P 11 x 10 1/2 x 8
293
MOISTURE CONTROL SYSTEM
02904102 MCS120-8CT
8” Moisture Control System
120
15
4 1500 210 5-15P 11 x 10 1/2 x 8
372
