2600 Series Downflow Unit Heater
5700 Series Confined Space Plenum Rated Heater
A
E
C
B
D
F
G
• Easily fits between joists for typical installation.
• Zero clearance for wall and ceiling mounting as well as
floor mounting with appropriate inlet and outlet clearances.
• Bracket standard or can be mounted by 3/8” threaded rod
(field supplied)
• Automatic reset thermal limit for safety
• 1 Phase model wattage field changeable from 1874 to 5000
Watts.
• 24V control circuit on three phase models with hydraulic
thermostat
• Made in U.S.A
Features
Standard Models
Field Installed Accessories
A B
C D E
F G
14.4” 19.4” 14.5” 8.4” 5.1” 9.2” 1.8”
Product Dimensions
Conforms to ANSI/UL 1995
Certified to CAN/CSA C 22.2 No.236-11
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
WATTS BTU's VOLTS PHASE AMPS TEMP RISE TEMP RANGE AIR
THROW CFM WT.
(LBS)
07262402 HF5705T
5000
17065
240
1
21
57
o
F
16'
275
32
4165
14215
17
48
o
F
(40
o
F-120
o
F)
3332
11365
14
38
o
F
2500
8533
10
29
o
F
3750
12798
208
1
18
43
o
F
32
3123
10659
15
36
o
F
2500
8553
12
29
o
F
(40
o
F-120
o
F)
16'
275
1874
6396
9
21
o
F
07262502 H3H5705T
3750
12799
208
3
10.4
57
o
F
(40
o
F-110
o
F)
16’
375
32
5000
17065
240
3
12
57
o
F
16'
275
32
07262602 P3P5705T
5000
17065
480
3
6
57
o
F
(40
o
F-110
o
F)
16'
275
32
07073602 DCS-MT303
Optional Field Installed Disconnect Switch, 30 Amp @ 600Volts
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
DESCRIPTION
06926302 FSW5112
Summer Fan Switch
06911002 TC1602
Wall Mounted Stratification Thermostat
Range - (40
o
F - 120
o
F)
07177502 A1600 Ceiling Mount Bracket 5-20 KW Models
07177602 A1601 Ceiling Mount Bracket 25-50 KW Models
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
DESCRIPTION
07177902 D1602
Linear Louvered Diffuser 5-20 KW Models
07178002 D1612
Linear Louvered Diffuser 25-50 KW Models
07178102 D1600 Radial Louvered Cone Diffuser 5-20 KW Models
07178202 D1610 Radial Louvered Cone Diffuser 25-50 KW Models
07178302 D1603
Anemostat Diffuser 5-20 KW Models
07178402 D1613
Anemostat Diffuser 25-50 KW Models
