26

Custom Specified Models

Note: Amps include motor Amp loads.

LENGTH

KW Elements per

Heat Deck

CFM

1-PHASE UNITS - AMPS (HIGH)

3-PHASE UNITS - AMPS (HIGH)

208V 240V 277V 600V 208V 240V

480V

600V

High Low Left

Right

High Low

3-WIRE

33”

2

1

2

250

230

10.6

9.3

8.12

3.8

9.2

8.1

4.1

3.3

3

2

3

15.4

13.5

11.7

5.5

9.2

8.1

4.1

3.4

4

2

4

20.2

16.7

15.3

7.2

13.4

11.8

6

6.22

5

3

5

25

21.8

19

8

17.6

15.4

7.8

5.5

6

3

6

29.9

26

22.6

10.5

17.6

15.4

7.8

6.3

46”

4

2

2

500

460

21.1

18.6

16

7.46

18.7

16.2

8.1

6.5

6

4

3

30.8

26.9

23.1 10.79 18.4

16.2

8.1

6.5

8

4

4

40.4

35.2

30.5 14.12 26.7

23.4

11.7

9.4

10

6

5

50

43.6

37.7

17.5

35.1

30.7

15.4 12.3

12

6

6

59.6

51.9

44.9

20.8

35.1

30.7

15.4 12.3

66”

6

3

2

2

750

690

31.8

27.9

24.1

11.3

27.6

24.3

12.3

9.8

9

6

3

3

46.2

40.4

35

16.3

27.6

24.3

12.3

9.9

12

6

4

4

60.6

52.9

45.8

21.3

40.1

35.2

17.7 15.6

15

9

5

5

75

65.4

56.7

25.5

52.6

46.1

23.1 15.7

18

9

6

6

89.4

77.9

67.5

31.3

52.6

46.1

23.1 18.5

79”

8

4

2

2

1000 920

42.3

37.1

32

14.9

36.7

32.3

16.2

13

12

8

3

3

61.5

53.8

46.5

21.6

36.7

32.3

16.2

13

16

8

4

4

80.7

70.5

61

28.2

53.4

46.8

23.5 18.8

20

12

5

5

NA 87.1

75.4

34.9

70.1

61.4

30.7 24.6

24

12

6

6

NA NA 89.8

41.6

70.1

61.4

30.7 24.6

“T” Series Multiple Angle Cabinet Unit Heater

HOW TO DESIGNATE A MODEL:

Series Number

Cabinet Size

33=33” 46 = 46” 66 = 66” 79 = 79”

Element KW

2KW through 24KW

See model chart for length and KW options.

Element Voltage

20 = 208V 24 = 240V 27 = 277V

41 = 415V 48 = 480V 57 = 600V

Phase

1 = Single Phase 3 = Three Phase

Number of Wires in Electrical Service

2, 3, or 4

Control Options

B1, B2, B3, B4, B5, B6, B7, B8

(see control options chart)

Motor Fusing Option

M = Required O = Not Required

Disposable Filter Option

F = Required O = Not Required

Summer Fan Switch

S = Included O = Not Included

Disconnect Option

C = Circuit Breaker D = Disconnect Switch

Air Flow Configuration

A = Bottom in / Top out B = Bottom in / Front out

D = Front in / Front out

C = Front in / Top out

O = None

T 46 D 08 24 1 2 B3 S D O F

Step 1

Step 2

Step 3

Step 4

Step 5

Step 6

Step 7

Step 8

Step 9

Step 10

Step 11

Step 12
