5600 Series Multiple Wattage Fan Forced Unit Heater
Product Specifications
CASING & CONSTRUCTION:
Fabricated of die formed, heavy gauge
steel and finished with two tone, brown
and beige, durable powder coated paint.
Supply air is drawn through the rear heavy
duty expanded steel inlet grill. Heated
air is discharged through front adjustable
louvers, which are spring loaded for
individual adjustment. Made in U.S.A.
ELEMENT:
Heavy-duty block fin
element design. The multiple tap electric
connection design allows field conversion
to eight wattage settings at 208/240-Volt
single phase or 240/480 Volt, 3 phase.
Units are available on special order with a
specific wattage/voltage setting.
MOTOR:
Motor shall be totally enclosed,
permanently lubricated, all angle industrial
rated with thermal overload protection.
WIRING:
Wiring to terminal block
adjacent to incoming knockout in
accordance with NEC and local codes.
THERMAL OVERLOAD:
All heaters shall be equipped with
an automatic reset thermal cutout to shut down the element and
motor circuits if unsafe operating temperatures are exceeded.
CONTROLS:
The heater shall have a heavy-duty hydraulic thermostat factory installed and wired. All controls
and wiring shall be in a large wiring compartment with hinged door for easy access. An optional disconnect switch
shall be available for field installation.
MOUNTING:
Heaters are standard with a three position-mounting bracket for wall, ceiling or workbench. Heaters
can be mounted for horizontal or vertical discharge. Note: Minimum mounting height is 6 feet, and minimum
distance from side of heater to nearest wall is 6 inches. Note: Approved for residential applications.
Standard Models
Product Dimensions
Front view
A B
C D E
F G
14” 12-11/16” 14” 1-9/16” 1-9/16” 9” 2-3/4”
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
WATTS
BTU's
VOLTS PHASE AMPS
TEMP
RISE
AIR
THROW CFM WT.
(LBS)
07072802 HF5605T
5000
17065
240
1
21
57
o
F
16'
275
32
4165
14215
17
48
o
F
3332
11365
14
38
o
F
2500
8533
10
29
o
F
3750
12798
208
1
18
43
o
F
32
3123
10659
15
36
o
F
2500
8553
12
29
o
F
16'
275
1874
6396
9
21
o
F
07072902 H3H5605T
3750
12799
208
3
10.4
57
o
F
16’
375
32
5000
17065
240
3
12
57
o
F
16'
275
32
07073002 P3P5605T
5000
17065
480
3
6
57
o
F
16'
275
32
07073602 DCS-MT303
Optional Field Installed Disconnect Switch, 30 Amp @ 600Volts
For 24V control on single phase models delete "T" suffix
