3000 Series Midsized Commercial Fan Forced Wall Heater - Multiple Wattage
• Wattage selectable at time of installation.
• Models shipped wired to highest wattage.
• Approved for horizontal mounting - right or left discharge.
• Fan purge circuit.
• Disconnect switch.
• Drywall depth embossments on back can.
• 18 gauge powder coated steel & extruded Aluminum front.
• Manual reset thermal limit.
• Steel block fin element.
• Propeller style fan blade: 1060 RPM motor; 100 CFM.
• Weight 6 lbs.
• Rough in dimensions: 9-1/4” Wide x 12-1/8” High x 3-5/8” Deep.
• Grill dimensions: 10” Wide x 13-1/8” High.
• Approved for wall or ceiling installation.
• Made in U.S.A.
Features
Standard Models
Accessories
MFG CATALOG
NUMBER
MFG MODEL
NUMBER
SELECTABLE INSTALLATION WATTAGE
MAX
BTU’s
VOLTS MAX
AMPS
TAMPERPROOF IN-BUILT DOUBLE POLE THERMOSTAT (40º - 100º TEMPERATURE RANGE)
09962102
E3055T2DWB
750 or 1500
5120
120
12.5
09962202
E3058T2DWB
900 or 1800
6143
120
15.0
09962502
F3052T2DWB
1000 or 2000
6826
208
8.3
09456902
F30522T2DWB
500 or 750 or 1000 or 1250
7680
208
10.8
or 1500 or 1750 or 2250
09962802
H3052T2DWB
750 or 1000 - 1500 or 2000
6826 208 / 240
8.3
09457202
H30522T2DWB
500 or 750 or 1000 or 1250
7680
240
9.4
or 1500 or 1750 or 2250
09963102
G3052T2DWB
2000
6826
277
7.2
TAMPERPROOF IN-BUILT SINGLE POLE THERMOSTAT (0º - 110º TEMPERATURE RANGE)
09960602
E3055TDWB
750 or 1500
5120
120
12.5
09960702
E3058TDWB
900 or 1800
6143
120
15.0
09961002
F3052TDWB
1000 or 2000
6826
208
8.3
09456302
F30522TDWB
500 or 750 or 1000 or 1250
7680
208
10.8
or 1500 or 1750 or 2250
09961302
H3052TDWB
750 or 1000 - 1500 or 2000
6826 208 / 240
8.3
09456602
H30522TDWB
500 or 750 or 1000 or 1250
7680
240
9.4
or 1500 or 1750 or 2250
09961602
G3052TDWB
2000
6826
277
7.2
MFG CATALOG
NUMBER
MFG MODEL
NUMBER
DESCRIPTION
09969402
305EX8
1” EXTENDER
09969302
305EX16
2” EXTENDER
09969202
305EX32
4” SURFACE MOUNT FRAME
