Draft Barrier Heaters - General Product Information
All Draft Barrier Heaters, unless otherwise noted, are build to order items. Consult factory for lead times.
Additional charges may be incurred if changes are made after production has begun - consult factory.
Electric Draft Barrier Features
How To Designate A Model
NOTE:
• Extended enclosures and
Blank Sections are NOT
punched. When a Control
Section is specified,ALWAYS
allow for an extended
enclosure to compensate for
the 6” or 12” length of the
Section required.
• Note on order when finished
backs are required and add
list adder to model list.
•
Total heater amperage must
notexceedthe25-Amprating
of the high temperature limit
at any voltage or wattage.
This applies to all Sill Line
Model Series.
*Units with Extended Enclosures may require more Pedestals than standard length, must verify length of heater after extended enclosures for
total amount of pedestals. NOTE: All bottom inlet units must be mounted a minimum of 3 inches above finished floor.
Dual element models DBCT/DBCF and ASHDB. All elements are single phase. Consult factory for more information.
Voltage & Wattage Specification
Control Options
• “UNI-LOCK” construction allows snap-fit, 2 piece installation
• Heavy Gauge Aluminum Extruded enclosures, 6063 heat
treated to T-5 hardness
a. DBT/DBF & RDBT-PD-12 gauge front & back
b. DBCT/DBCF- 10 gauge Front & Back
c. CB-14 gauge Front & Back
• ASHDB Series is 16 gauge Steel Front with 18 Steel gauge back
• 1/4” pencil proof discharge louvers
• Thermal protection by full length linear limits
• Multiple heaters, factory wired on same back plate,
available in up to 10’ lengths
• Totally enclosed junction boxes
• Custom colors and finishes available (See Chart )
• Enclosures available for hydronic heating coils
(consult factory for more information )
DIGIT
(EXAMPLE)
MFG MODEL NUMBER DESIGNATION - “ASI” DRAFT BARRIER
Digit 1=
DBT
Series Model Number ( DBT/DBF, CB, Etc.)
Digit 2=
PD
Use if Pedestals are Required*
2’ to 5’ Heaters require 2 pedestals
6’ to 8’ Heaters require 3 pedestals
9’ & 10’ Heaters require 4 pedestals
Digit 3=
4
Heated Length of Heater
(for extended enclosure, specify amount of required enclosure on
order write up, IE: 4’ Heated length w/ 2’6” of extended enclosure)
Digit 4=
250
Wattage per Linear foot ( may not exceed allowable wattages
on specific models, refer to catalogue page to verify maximum WPF)
Digit 5=
ITS (etc)
Control Options ; Refer to List Price chart for available options
( Verify on each model which options may be factory installed )
Completed example: DBT-PD-4250-ITS
VOLTAGE
STANDARD WATTAGES PER FOOT
HEATER LENGTHS
120-277
100, 125, 150, 165, 187, 200, 250*, 300, 333*, 375*
2’ through 10’
Note:
If using line voltage thermostat on single phase heaters you cannot exceed 25 Amps due to Amp rating
of thermostat. 347, 480, and 600V models can use up to 30 Amps with in-built thermostat.
CUSTOM PAINT COLORS
Durable Powder Coat Paint Finish
Bankers Bronze - standard color
Eggshell White
Black
Gray
Beige
Bronze Anodized*
*simulated powder
coat finish
Special Colors (5 lb. Increment)
ANODIZING*
* 204R1 Clear; 313R1 Bronze and Black
SUFFIX DESIGNATION
DESCRIPTION
CS 6
6” control section / will contain up to 2 control options
CS 12
12” control section / will contain up to 3 control options
ITS
Single Pole, 25 Amp integral thermostat, 120,208,240 & 277 Volts
ITD
Double Pole, 25 Amp integral thermostat, 120,208,240 & 277 Volts
IDS
Double Pole Disconnect, 20 Amp, 120, 208, 240 & 277 Volts
IDS 30
30 Amp disconnect (9300 Series)
IDS 40
40 Amp disconnect (9300 Series)
LVTR
Low voltage controls (trans & relay) (9300 Series)
PR 120-277/24
Power Relay, 18 Amp tested, Must specify coil voltage
Single Pole
PR 120-277/120
PR 120-277/240
ATR*
Single Pole, rated 25 Amps, 120 to 240 Volts,
Contacts rated up to 277 Volts (must specify )
Coils are 24 Volt; 24 Volt transformer
* Not suitable for International use
Note:
Please refer to each model to verify how many controls may be integrally mounted, Control sections will add length
to the heater. Must use control section with PR 240/24, PR 208/24, 208/208 and ATR
