DBTS Series Draft Barrier Heaters
Features
• Bottom air intake.
• Maximum watts per foot: 300.
• Dimensions: Depth 2-5/8'” x Height 4" Length 2’ to 10'.
• 14 gauge Aluminum housing.
• Voltages: 120V / 208V / 240V / 277V - 1 Phase
• No controls can be added without adding a control section and
extended enclosure.
• Made in U.S.A.
Standard Models
Accessories
Not suitable for residential applications. 300
watts per foot maximum. Built to order:
consult factory for lead time.
MFG MODEL NUMBER
DESCRIPTION
DBTS IC
Inside Corner Section
90° - 180°
DBTS OC
Outside Corner Section
180° - 270° - 6” longest side
DBTS ECR
Right Hand End Cap
DBTS ECL
Left Hand End Cap
DBTS IECR
Inside Fitting Right End Cap
DBTS IECL
Inside Fitting Left End Cap
DBTS WT
Wall Trim 2” - 6”
DBTS SP
Splice Plate 1 1/2”
DBTS MF
Mullion Front up to 1’
Note on order
1/2” Conduit Raceway
Mesh 1/4” Wire Mesh under grill
Pedestals - specify 2” or 3”
MFG MODEL NUMBER
LENGTH
HEATER
DBTS-2
2’
DBTS-3
3’
DBTS-4
4’
DBTS-5
5’
DBTS-6
6’
DBTS-7
7’
DBTS-8
8’
DBTS-9
9’
DBTS-10
10’
EXTENDED ENCLOSURE PER FOOT
BLANK SECTION
DBTS-100BS
1’
DBTS-200BS
2’
DBTS-300BS
3’
DBTS-400BS
4’
DBTS-500BS
5’
DBTS-600BS
6’
DBTS-700BS
7’
DBTS-800BS
8’
DBTS-900BS
9’
DBTS-1000BS
10’
