2016 Raywall Mechanical Heat & Controls Product Catalog

68 / 129

68
TH & THSS Series Mul-T-Mount Electric Infrared Heater
2 Lamp Mul-T-Mount Series
Brown Enamel Or Stainless Steel With 2 Clear Quartz Lamps Included
NOTE: Consult the factory, the product instruction manual, or a licensed electrician for 3-phase wiring of all 2-element heaters.
BROWN HOUSING STAINLESS Steel HOUSING
KW BTU’S VOLTS REFLECTORPATTERN
REPLACEMENT
ELEMENT
WT.
(LBS) MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
04441602 222-30-TH-208V 04444002 222-30-THSS-208V
3.2 10,922
208
30° Symmetrical
63016209
20
04441702 222-30-TH-240V 04444102 222-30-THSS-240V 240 63016249
04441802 222-30-TH-277V 04444202 222-30-THSS-277V 277 63016279
04813802 222-30-TH-480V 04814302 222-30-THSS-480V 480 63016489
04441902 222-A30-TH-208V 04444302 222-A30-THSS-208V 208
30° Asymmetrical
63016209
04442002 222-A30-TH-240V 04444402 222-A30-THSS-240V 240 63016249
04442102 222-A30-TH-277V 04444502 222-A30-THSS-277V 277 63016279
04814102 222-A30-TH-480V 04814602 222-A30-THSS-480V 480 63016489
04442202 222-60-TH-208V 04444602 222-60-THSS-208V 208
60° Symmetrical
63016209
04442302 222-60-TH-240V 04444702 222-60-THSS-240V 240 63016249
04442402 222-60-TH-277V 04444802 222-60-THSS-277V 277 63016279
04813902 222-60-TH-480V 04814402 222-60-THSS-480V 480 63016489
04442502 222-A60-TH-208V 04444902 222-A60-THSS-208V 208
60° Asymmetrical
63016209
04442602 222-A60-TH-240V 04445002 222-A60-THSS-240V 240 63016249
04442702 222-A60-TH-277V 04445102 222-A60-THSS-277V 277 63016279
04814202 222-A60-TH-480V 04814702 222-A60-THSS-480V 480 63016489
04432902 222-90-TH-208V 04445202 222-90-THSS-208V 208
90° Symmetrical
63016209
04442802 222-90-TH-240V 04445302 222-90-THSS-240V 240 63016249
04442902 222-90-TH-277V 04445402 222-90-THSS-277V 277 63016279
04814002 222-90-TH-480V 04814502 222-90-THSS-480V 480 63016489
04810802 342-30-TH-208V 04809302 342-30-THSS-208V
5.0 17,065
208
30° Symmetrical
63025209
25
04810902 342-30-TH-240V 04809402 342-30-THSS-240V 240 63025249
088026143 342-30-TH-480V 088026394 342-30-THSS-480V 480 63025489
04811702 342-A30-TH-208V 04810202 342-A30-THSS-208V 208
30° Asymmetrical
63025209
04811802 342-A30-TH-240V 04810302 342-A30-THSS-240V 240 63025249
04443102 342-A30-TH-480V 04445602 342-A30-THSS-480V 480 63025489
04811102 342-60-TH-208V 04809602 342-60-THSS-208V 208
60° Symmetrical
63025209
04811202 342-60-TH-240V 04809702 342-60-THSS-240V 240 63025249
088029143 342-60-TH-480V 088029394 342-60-THSS-480V 480 63025489
04812002 342-A60-TH-208V 04810502 342-A60-THSS-208V 208
60° Asymmetrical
63025209
04812102 342-A60-TH-240V 04810602 342-A60-THSS-240V 240 63025249
04443302 342-A60-TH-480V 04445802 342-A60-THSS-480V 480 63025489
04811402 342-90-TH-208V 04809902 342-90-THSS-208V 208
90° Symmetrical
63025209
04811502 342-90-TH-240V 04810002 342-90-THSS-240V 240 63025249
088032144 342-90-TH-480V 088032394 342-90-THSS-480V 480 63025489
088027143 462-30-TH-480V 088027393 462-30-THSS-480V
24,915 480
30° Symmetrical 63036489
32
04443602 462-A30-TH-480V 04446102 462-A30-THSS-480V 30° Asymmetrical 63036489
088030143 462-60-TH-480V 088030393 462-60-THSS-480V 7.3 60° Symmetrical 63036489
04443802 462-A60-TH-480V 04446302 462-A60-THSS-480V 60° Asymmetrical 63036489
088033144 462-90-TH-480V 088033394 462-90-THSS-480V 90° Symmetrical 63036489
