TH & THSS Series Mul-T-Mount Electric Infrared Heater
TH & THSS Series Product Accessories
3 Lamp Mul-T-Mount Series
Brown Enamel Or Stainless Steel Housing With 3 Clear Quartz Lamps Included
NOTE:
• 600-Volt Models also available, contact factory for more
information.
• Asymmetrical pattern units are also available for 30° & 60°
• Made in U.S.A.
MFG CATALOG NUMBER MFG MODEL NUMBER
DESCRIPTION
FOR USE WITH
WT.
(LBS)
08811202
VMB-41-SS
Wall Mounting Brackets (2)
All Mul-T-Mount Models
12
08511500
CHWG-222
Stainless Steel Wire Guards
222 Series
2
08511400
CHWG-342
342 Series
08516200
CHWG-462
462 Series
08543600
CHWG-223
223 Series
08543500
CHWG-343
343 Series
08543400
CHWG-463
463 Series
Recessed Mounting Frames (UL)
Ceiling Cutout (in.)
Frame Size (in.)
04419902
RMF-222-SS-A
27 x 17-7/8
29-1/8 x 20
222 Series Stainless
6
04494402
RMF-222-A
27 x 17-7/8
29-1/8 x 20
222 Series Painted
04420702
RMF-342-SS-A
36 x 17-7/8
38-1/8 x 20
342 Series Stainless
9
04418702
RMF-342-A
36 x 17-7/8
38-1/8 x 20
342 Series Painted
04421002
RMF-462-SS-A
49 x 17-7/8
51-1/8 x 20
462 Series Stainless
11
04494502
RMF-462-A
49 x 17-7/8
51-1/8 x 20
462 Series Painted
08811002
RMF-223-SS
32 x 29-3/8
34-1/8 x 31-1/2
223 Series Stainless
15
08811302
RMF-343-SS
41 x 29-3/8
43-1/8 x 31-1/2
343 Series Stainless
18
08811102
RMF-463-SS
54 x 29-3/8
56-1/8 x 31-1/2
463 Series Stainless
20
04877202
RMF-223
32 x 29-3/8
34-1/8 x 31-1/2
223 Series Painted
15
04877302
RMF-343
41 x 29-3/8
43-1/8 x 31-1/2
343 Series Painted
18
04877402
RMF-463
54 x 29-3/8
56-1/8 x 31-1/2
463 Series Painted
20
04407802
31939009
Red Vycor Sleeves
All 1600W Qtz. Lamp
2
04407302
31940009
Reduces Quartz Lamp
All 2500W Qtz. Lamp
04407402
31941009
Brightness by 90%
All 3650W Qtz. Lamp
04461502
632-1620
Red Quartz Lamps; 1.6kw, 208v
222,223 & RPH Series
2
04461602
632-1624
Red Quartz Lamps; 1.6kw, 240v
04462202
632-2548
Red Quartz Lamps; 2.5kw, 480v
342 & 343 Series
BROWN HOUSING
STAINLESS STEEL HOUSING
KW BTU’S VOLTS REFLECTOR
PATTERN
REPLACEMENT
ELEMENT
WT.
(LBS)
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
04874802 223-30-TH-208V 04436702 223-30-THSS-208V
4.8
16382
208
30°
Symmetrical
63016209
25
04874902 223-30-TH-240V 04436802 223-30-THSS-240V
240
63016249
04875002 223-30-TH-277V 04436902 223-30-THSS-277V
277
63016279
04875102 223-30-TH-480V 04815802 223-30-THSS-480V
480
63016489
04875202 223-60-TH-208V 04432802 223-60-THSS-208V
208
60°
Symmetrical
63016209
04875302 223-60-TH-240V 04437302 223-60-THSS-240V
240
63016249
04875402 223-60-TH-277V 04437402 223-60-THSS-277V
277
63016279
04875502 223-60-TH-480V 04815902 223-60-THSS-480V
480
63016489
04875602 223-90-TH-208V 04437802 223-90-THSS-208V
208
90°
Symmetrical
63016209
04875702 223-90-TH-240V 04437902 223-90-THSS-240V
240
63016249
04875802 223-90-TH-277V 04438002 223-90-THSS-277V
277
63016279
04875902 223-90-TH-480V 04816002 223-90-THSS-480V
480
63016489
04876002 343-30-TH-208V 04812302 343-30-THSS-208V
7.5
25298
208
30°
Symmetrical
63025209
33
04876102 343-30-TH-240V 04812402 343-30-THSS-240V
240
63025249
04876202 343-30-TH-480V 088114394 343-30-THSS-480V
480
63025489
04876302 343-60-TH-208V 04812602 343-60-THSS-208V
208
60°
Symmetrical
63025209
04876402 343-60-TH-240V 04812702 343-60-THSS-240V
240
63025249
04876502 343-60-TH-480V 088116394 343-60-THSS-480V
480
63025489
04876602 343-90-TH-208V 04812902 343-90-THSS-208V
208
90°
Symmetrical
63025209
04876702 343-90-TH-240V 04813002 343-90-THSS-240V
240
63025249
04876802 343-90-TH-480V 088118394 343-90-THSS-480V
480
63025489
04876902 463-30-TH-480V 088105394 463-30-THSS-480V
37372
480
30° Sym.
63036489
41
04877002 463-60-TH-480V 088107394 463-60-THSS-480V 10.95
60° Sym.
63036489
04877102 463-90-TH-480V 088109394 463-90-THSS-480V
90° Sym.
63036489
