Electric Infrared Heating Controls
Snow & Ice Detectors
Variable Controllers
APS-3C
CIT-1
• Main control unit for Automatic Snow & Ice Control Systems.
• By sensing both temperature and moisture the system activates and melts any
snow & ice accumulations until conditions subside.
• NEMA 3R Enclosure is UL Listed and houses timers and switching electronics
to operate the system.
• Capability to monitor up to 6 sensors (CIT-1).
• Unit can be manually activated and can be controlled and monitored from an
optional remote switch (Model RCU-).
• Positioned above ground to maximize the sensors capability.
• Detects falling or blowing of precipitation such as snow when the
temperature is below 38° F.
• Most common sensor device.
Note: Any snow & ice control system should be used with the correct sized control panel (with contactors & fusing) as supplied by factory
or your electrical contractor. The APS-3C requires a control device (RCU-1, CIT-1, SIT-6E) in order to operate properly and must use 120V.
VHC-15
18D-2-80CF ENC.
VHC-32
30-Amp or 80-Amp Enclosed
• Solid state variable device controls
heat loads up to 15-Amps.
• 208/240Volt “In-Line” Controller.
• Built in On/Off knob switch with
positive “off” & surface plate
included.
• Designed for a 2” x 4” electrical
wall box mounting (not supplied).
• Must be mounted in a protected
area.
• Can only operate Fostoria Quartz
Tube Infrared Heaters.
• SCR Voltage Controller - 80 Amp MAX.
• Includes (1) 24-volt Potentiometer (3” square)
to control the heat output.
• Only operates Quartz Lamps at 240 or
208-Volts, single phase only.
• Potentiometer can be mounted outside, but the
SCR must be located in a protected area.
• Factory wired with millisecond fuses included.
• Solid State phase angle variable
“Triac” knob controller adjusts
heat settings from 10-100% with
heat loads up to 15.4-Amps.
• 208/240 VAC single-phase, single
stage controller, 3200 Watt max.
• Positive “Off” & built-in On/Off
Rocker switch lights “red” during
operation.
• NEMA1Aluminumenclosure with
stainless steel face plate designed
for wall mounting or suitable for
semi-recessed applications.
• Must be mounted in a protected
area.
• Can either operate Quartz Lamps
or Quartz Tube Infrared Heaters.
Note: Installer to provide overload protection for all infrared heaters.
Contactor Enclosures
• Economical load handling / switch device, ideal for use with other control equipment.
• NEMA 1 Enclosures.
• Load rating up to 600V Max., 3-Pole.
• Magnetic contactor.
FEC-30-120
MFG CATALOG
NUMBER
MFG MODEL
NUMBER
DESCRIPTION
DIMENSION (IN.)
WT.
(LBS)
Depth
Width
Height
03196100
APS-3C
Snow / Ice Control Switch
6.56
11.5
9.25
8
03197600
CIT-1
General Purpose Snow Sensor
3.25
3.25
4.13
1
MFG CATALOG
NUMBER
MFG MODEL
NUMBER
DESCRIPTION
DIMENSION (IN.)
WT.
(LBS)
Depth
Width
Height
04853502
VHC-32
Variable Heat Controller 208/240-Volt; 15.4 Amp
3
5
5
3
04459402
VHC-15
Variable Heat Controller; 208/240-Volt; 15 Amp
3
5
5
3
04456302
18D-2-30CF (Open)
SCR Controller - 26 Amp MAX; No Enclosure
6
6
9
11
04456402 18D-2-30CF (Enclosed)
SCR Controller - 26 Amp MAX; Enclosure Included
8
10
12
15
04456502 18D-2-80CF (Enclosed)
SCR Controller - 80 Amp MAX; Enclosure Included
8
12
14
29
MFG CATALOG
NUMBER
MFG MODEL
NUMBER
CONTACTOR
AMPS
COIL
VOLTAGE
CABINET SIZE (IN.)
WT.
(LBS)
Depth Width Height
04408502
FEC-30-120
30
120
5
6
10
5
04408602
FEC-30-240
208/240
04408702
FEC-60-120
60
120
04408802
FEC-60-240
208/240
