Electric Infrared Heating Elements
Clear & Red Quartz Lamps
Quartz Tubes
Flat Panel Emitter Replacement Complete Conversion Kits - MR, CH, & FHK
Notes:
Life expectancy of all heating elements - 5,000 hours.
All heating elements operate at 50 / 60 Hertz.
Model prefix types:
630 = Horizontal Burning “Clear”
631 = Vertical OR Horizontal Burning
“Clear”
632 = Horizontal Burning “Red”
*3/8” Diameter
• Medium wavelength infrared, color
temp. emitting approx. 1800°F (bright
orange glow)
• Approximately 60% radiant efficiency
• Nickel-Chromium alloy coiled
element with porcelain end caps and
pigtailed termination
• 5/8” Diameter frosted quartz envelope
• Fast heat-up/cool-down
Notes: Life expectancy of all heating elements - 5,000 hours.
All heating elements operate at 50 / 60 Hertz.
• Near wavelength infrared, color temp.
emitted: approx. 4100° F (high brightness).
• Approximately 96% radiant efficiency.
• Excellent resistance to thermal shock.
• Highest moisture resistance and quickest
heat-up time.
• 3/8” Diameter clear or red quartz envelope.
• Coiled tungsten filament; sealed porcelain
end caps; halogen gas filled.
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
WATTS VOLTS
LENGTH (IN.)
FITS
MODEL
Overall
Heated
04432302 671-3784
1500
120
39-11/16
34-3/16
OCH-46
04418102 671-5061
2000
208
39-11/16
34-3/16
04418002 671-3785
2000
240
39-11/16
34-3/16
04419302 671-5018
2000
277
39-11/16
34-3/16
04416602 671-5060
3000
208
50-11/16
45-3/16
OCH-57
04414702 671-3786
3000
240
50-11/16
45-3/16
04419402 671-5059
3000
277
50-11/16
45-3/16
04419502 671-5058
2250
480
50-11/16
45-3/16
04403502 671-3454
450
120
12-15/16
8-7/16
FFH-912B
04400802 671-3492*
550
120
19-1/2
16
FFH-512A
04462402 671-5056
1000
120
18-5/16
14-7/16 CH-2212-1C
04462502 671-5057
1425
240
27-5/16
23-7/16 CH-6424-1C
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
WATTS VOLTS
LENGTH (IN.)
ENVELOPE
TYPE
FITS
MODEL
Overall
Heated
04400502 630-05129 500
120
8-11/16
5
CLEAR
MM-13A
04401602 630-16209
1600
208
19-11/16
16
222, 223,
or MM-24A
04401702 630-16249
240
04409902 631-16249
240
04401802 630-16279
277
04817302 630-16489
480
04817402 630-25209
2500
208
28-11/16
25
342, 343,
or MM-33A
04817502 630-25249
240
04817602 630-25279
277
04405402 630-25489
480
04403602 631-25489
480
04406802 631-25609
600
04406702 630-36489 3650
480
41-11/16
38
462, 463,
or MM-46A
04462302 630-38579 3800
600
04441302 631-38579
600
04461502 632-1620 1600
208 19-11/16
16
RED
222/223
or RPH
04461602 632-1624
240
04462202 632-2548 2500
480 28-11/16
25
342 or 343
CH & MR SERIES - FLAT PANEL EMITTER CONVERSION KITS
MFG CATALOG
NUMBER
MFG MODEL
NUMBER
WATTS
VOLTS
FOR USE WITH OLD MODEL #:
01358102
64337-022
3150
208
MR-420-1, CH-420-1C, CH-420-3A
01358202
64337-023
240
MR-424-1, CH-424-1C, CH-424-1A
01358302
64337-024
277
MR-427-1, CH-427-1C, CH-427-1A
01358402
64337-025
480
MR-448-1, CH-448-1C, CH-448-1A
01358502
64337-026
600
MR-457-1, CH-457-1C, CH-457-1A
01358602
64337-027
4300
208
MR-620-3, CH-620-3C, CH-620-3A
01358702
64337-028
240
MR-624-3, CH-624-3C, CH-624-3A
01358802
64337-029
277
MR-627-3, CH-627-3C, CH-627-3A
01358902
64337-030
480
MR-648-3, CH-648-3C, CH-648-3A
01359002
64337-031
600
MR-657-3, CH-657-3C, CH-657-3A
01359102
64337-032
9500
208
MR-1320-3, CH-1320-3B, CH-1320-3A
01359202
64337-033
240
MR-1324-3, CH-1324-3B, CH-1324-3A
01359302
64337-034
277
MR-1327-3, CH-1327-3B, CH-1327-3A
01359402
64337-035
480
MR-1348-3, CH-1348-3B, CH-1348-3A
01359502
64337-036
600
MR-1357-3, CH-1357-3B, CH-1357-3A
01359602
64337-037
9500
208
MR-2720-3, CH-2720-3C, CH-2720-3B
01359702
64337-038
240
MR-2724-3, CH-2724-3C, CH-2724-3B
01359802
64337-039
277
MR-2727-3, CH-2724-3C, CH-2724-3B
01359902
64337-040
480
MR-2748-3, CH-2748-3C, CH-2748-3B
01360002
64337-041
600
MR-2757-3, CH-2757-3C, CH-2757-3B
FHK Series - Flat Panel Emitter Conversion Kits
01360802
64337-049
4300
208
FHK-620-3A
01360902
64337-050
240
FHK-624-3A
01361002
64337-051
480
FHK-648-3A
01361102
64337-052
9500
208
FHK-1320-3A
01361202
64337-053
240
FHK-1324-3A
01361302
64337-054
480
FHK-1348-3A
Note: There are no element replacement kits for CH-2, MR-2, or FHK-2 model series heaters.
