Electric Infrared Heating Controls - FPC Control Panels
Pre-Wired Contactor Panels
FPC2120
• Factory pre-wired for quick installation,
with the following optional equipment:
Snow & Ice Detector (APS-3C)
Single & Two-Stage Thermostats
Two-stage thermostats require a
minimum 2-contactors.
Note: Contact factory for 3R, 4, 4X, & NEMA 12 “special” built models.
• Step-down transformer and secondary
fusing for 24V or 120V control circuit.
• 3-Phase load rated.
• Fuses are NOT included.
• NEMA 1 Enclosures.
• Max 50-Amp branch circuit fusing.
• Made in U.S.A.
IMPORTANT FUSING INFORMATION
Fuses are NOT included since panels can be used with various infrared heat sources. Quartz
Lamp Heat Sources: Use FRS-600V (or equal) “Time Delay” fuses; Class RK-5. Quartz Tube &
metal Sheath Heat Sources: Use KTS-R 600V (or equal) “Fast Acting” fuses; Class RK-1. Fuse
circuits as close to calculated load as possible. Circuits less than 35 Amps will require the use of
fuse reducers. *One heater only per circuit.
Standard Models
120-V CONTROL SYSTEM 24-V CONTROL SYSTEM
MAX
AMPS VOLTS
CABINET SIZE (IN.)
WT.
(LBS)
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
DEPTH WIDTH HEIGHT
04459902
FPC8110
04864302
FPC8210
50
208
6.75
16
24
52
04460002
FPC2110
04864402
FPC2210
240
04460102
FPC7110
04864502
FPC7210
277/480
04460202
FPC4110
04864602
FPC4210
480
04460302
FPC8120
04864702
FPC8220
100
208
6.75
16
24
70
04460402
FPC2120
04864802
FPC2220
240
04460502
FPC7120
04864902
FPC7220
277/480
04460602
FPC4120
04865002
FPC4220
480
04460702
FPC8140
04865102
FPC8240
200
208
6.75
24
30
88
04460802
FPC2140
04865202
FPC2240
240
04460902
FPC7140
04865302
FPC7240
277/480
04461002
FPC4140
04865402
FPC4240
480
04461102
FPC8160
04865502
FPC8260
300
208
6.75
30
36
106
04461202
FPC2160
04865602
FPC2260
240
04461302
FPC7160
04865702
FPC7260
277/480
04461402
FPC4160
04865802
FPC4260
480
