PCH Series Portable Quartz Infrared Spot Heater
Portable Infrared Instant On-Off Heat Gun
CH Series Portable Quartz Infrared Heater
MODELCH 2212-1C
has two 1000 Watt elements that can be switched on / off by toggle switches to produce
1000 Watts or 2000 Watts of heat. - 15’ cord and NEMA 5-20 molded plug.
MODEL CH 6424-1C
has two sets of 1425 Watt elements that can be switched on / off by toggle switches to
produce 2850 Watts or 5700 Watts of heat. - 15’ cord and NEMA L6-30 twist lock plug.
• 60° symmetrical heat pattern.
• Quartz tubes and built in wire guards included.
• Interior or protected outdoor use only.
• GOLD anodized Aluminum reflector and end caps.
• Made in U.S.A.
Chain mounted
CH 2212-1C
Portable Cart Unit CH 6424-1C
with FHK-1 Cart
Listed
for
overhead
operation
Note: CH-2212-1C operates
with a 20- Amp molded plug.
Note: CH-6424-1C operates with a
30- Amp twist lock plug.
Features
Portable Electric Infrared Heat Panels
HP-11-QT
• Portable panels are built to withstand rigors of industrial and heavy-commercial applications,
such as auto collision repair shops.
• 20 gauge steel frame, base, and housing construction.
• Made in U.S.A.
• 3” steel casters for high stability and ease of mobility
• Gold anodized Aluminum reflectors and end caps allow 10% faster cure time than polished
Aluminum reflectors, especially in paint and dust-laden atmospheres.
• Elements achieve full temperature in less than 2 minutes
• Fused disconnect switches are installed on the back of each unit.
• Units are positioned with adjustable hinges allowing the user to use direct heat more precisely
to the target area.
• Gentle but effective medium-wave radiant heat can quickly boost, flash-off, or cure a variety
of finishes, and lessens the chance of blistering and/or overheating the coating.
• Medium-wave infrared heating elements are also effective for flash-off of water-based clear
coatings being mandated by environmental agencies in many states.
Features
Standard Models
General Curing Guidelines
Note: Curing times will vary depending on material and shop conditions. This chart is based on distances of 18-24” away from the target area.
Material Type
Solvent Based
Primer
Water Based
Primer
Two Component
Primer
Water Based
Clear Coat
Acrylic enamel &
Polyurethane Clear Coat
Urethane Clear Coat &
High Solids Top Coat
Curing Time
3-5 mins
3-6 mins
8-20 mins
3-10 mins
12-30 mins
10-30 mins
HP-5-QT
Width: 53”
Height: 2-6’
Depth: 28”
Features
• Provides instant spot heat in a
controlled pattern
• Spot cure retouched paint and other
finishes
• De-wrinkle or relax materials such
as cloth-vinyl-leather
• T-3 Tungsten IR lamp
• Ergonomically friendly, easy-grip
handle
• Suitable for portable spot heat or for
curing clear coat paint
• Height adjustable from 2’ to 4’
• On-Off rocker switch standard
• 4 casters included; Tip-Over power
cutoff safety switch
• 60
o
symmetrical heat pattern
• 5/8” diameter quartz tube included
• Average element life is 5000 hours
• Bright Aluminum reflector and end caps
• 20 gauge powder coated Steel housing
• 15’ long, 3 wire (14/3) cordset with standard 3 pring NEMA 5-20P
• Made in U.S.A.
• 20’ long, 18/3 grd. cordset with GFCI plug
• Made in U.S.A.
MFG CATALOG
NUMBER
MFG MODEL
NUMBER
KW BTU's
VOLTS PHASE AMPS WT. (LBS)
08840910
CH-2212-1C 2.0 / 1.0 6826 / 3413
120
1
16.7 / 8.35
16
08841010
CH-6424-1C 5.7 / 2.85 19454 / 9727 240
1
23.8 / 11.9
31
08524002
FHK-1
OPTIONAL CART
20
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
WATTS BTU’s VOLTS PHASE WT.
(LBS)
08841110 PCH-48C 1500 5120
120
1
30
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
WATTS VOLTS AMPS HEAT
SOURCES
CABLE
TYPE (20’)
DIMENSION (IN.) HEATED AREA (IN.) WT.
(LBS)
Width Height
Width Height
08841202 HP-5-QT 4,800
240
20
4
12-3 SO 44-5/8 56-1/2
40
44
116
08841302 HP-6-QT 6,400
26.7
4
66-5/8
61
141
08841402 HP-11-QT 11,200
46.7
7
6-3 SO
89-1/2
77
225
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
WATTS VOLTS AMPS WT.
(LBS)
05922802 RHG-1012A 1000
120
8.4
3
