96 / 129
96
5"
7"
3"
8.75"
48"
CORD LENGTH: 6'10"
16AWG USASI HPN CORD
CORD LENGTH: 25'
18AWG SHIELDED CABLE
H
L
W
HANDLE ADDS 6" TO L"
10.625"
5"
7"
3"
8.75"
48"
CORD LENGTH: 6'10"
16AWG USASI HPN CORD
CORD LENGTH: 25'
18AWG SHIELDED CABLE
H
L
W
HANDLE ADDS 6" TO L"
10.625"
H
L
W
H
L
W
H
L
W
H
L
W
Thermal Area Treatment Heaters
Standard Models
Product Dimensions
MFG MODEL NUMBER
DIMENSIONS
WT.
(LBS)
LENGTH
WIDTH
HEIGHT
TAT-8-240-1
39”
26.5”
18”
180
TAT-5-240-1
39”
26.5”
18”
180
TAT-20-480-3
39”
30.5
18”
234
TAT-1-120-1
48”
8.5”
9.5”
23
Remote Timer
11”
3”
4.5”
5
TAT 30, 45
37”
24”
39”
115/125
TAT24-FAN-120V-1
10.5”
26”
26”
30
*208 Volt models do not have a cord supplied
Accessories
• Single speed
• Head tilts 360
o
• Coated steel guards
• SJT type 3 conductor
• Steel hub / Aluminum blades
• Meets OSHA standards
• Made in U.S.A. with domestic
and foreign components
TAT-24-FAN-120V-1
TAT 30-45
• Safety yellow heater enclosure with safety screens
on both air intake and output openings.
• Optional 25’ long SO type cord, ready for plug
attachment is available for each model.
• Long-life finned tubular heating elements.
• Thermostat adjustment 115° to 150° F.
• Two 10” rear wheels and a front locking caster.
• High-limit thermal cutout switch with manual reset.
• 2200 CFM
• Fan only operation feature
• Made in U.S.A.
MFG
CATALOG
NUMBER
MFG
STYLE MODEL
NUMBER
BASE
UNIT
KW
BASEBOARD
PERIMETER
HEATER KW
TOTAL
SYSTEM
KW
BASE
UNIT
VOLTS
BASEBOARD
PERIMETER
HEATER
VOLTS
PH
BASE
UNIT
AMP
BASEBOARD
PERIMETER
AMP-EACH
CIRCUIT (3)
PLUG TYPE
BASE UNIT PERIMETER
03975602 TAT5-240-1/3BB/1T 5.3 1.5 (X3)
9.8
240
120
1 24
12.5
Nema 10-30 Nema 5-15
03976202 TAT5-208-1/3BB/1T* 5.3
1.5 (x3)
9.8
208
120
1 27
12.5
----
Nema 5-15
03975502 TAT8-240-1/3BB/1T 8.4 1.5 (X3)
12.9 240
120
1 37
12.5
Nema 14-50 Nema 5-15
03976102 TAT8-208-1/3BB/1T* 8.4
1.5 (x3)
12.9 208
120
1 42
12.5
----
Nema 5-15
03975202 TAT20-480-3/3BB/1T 20
1.5 (X3)
24.5 480
120
3 26
12.5
Nema L16-30 Nema 5-15
03975802
TAT-ILC-25
25’ Shielded Cable
MFG CATALOG
NUMBER
MFG MODEL
NUMBER
DESCRIPTION
HP CFM / RPM MAX
AMPS VOLTS
WT.
(LBS)
03976302
TAT-24-FAN-120V-1
Thermal Area Treatment Floor Fan
1/3
5000/1160
3.1
120
30
MFG CATALOG
NUMBER
MFG STYLE
MODEL NUMBER
DESCRIPTION
KW BTU VOLTS PHASE AMPS TEMP
RISE
WT.
(LBS)
03981902
TAT-30/1T
30KW Salamander
30
102390
480
3
36
43
115
03982002
TAT-45/1T
45KW Salamander
45
153585
480
3
54.2
70
125
