UH Series Horizontal Fan Forced Unit Heater
Standard Product Models
Factory & Field Installed Accessories
NOTE:
Factory installed heat purge fan delay option (F) requires
unit to have CA1 or CA2 factory installed
FACTORY INSTALLED OPTIONS
SUFFIX
DESCRIPTION
F
Heat purge fan delay switch for 208 / 240 / 277V units
(includes contactor & transformer)
Heat purge fan delay switch for 480V units
(contactor & transformer standard in unit)
S
Summer fan switch
CA1 24V Transformer (3.3 KW - 15 KW units) & Contactor
CA2 120V Transformer (3.3 KW - 15 KW units) & Contactor
E
Epoxy Coating
T
SPST Thermostat
D
Disconnect Switch - 30 Amps
Disconnect Switch - 40 Amps
Disconnect Switch - 80 Amps
Disconnect Switch - 100 Amps
FIELD INSTALLED ACCESSORIES
UPC# MODEL
DESCRIPTION
686334
646239 DCS303
30 Amp Disconnect Kit
646246 DCS403
40 Amp Disconnect Kit
646253 DCS803
80 Amp Disconnect Kit
646260 DCS1003
100 Amp Disconnect Kit
687997 TUH1
25 Amp SPST Thermostat Kit
699105 UHB-1
wall / ceiling bracket - 3.3 KW - 15 KW units
699112 UHB-3
wall / ceiling bracket - 20 KW - 30 KW units
699129 UHB-4
wall / ceiling bracket - 35 KW - 48 KW units
UPC#
686334
MODEL
KW
BTU'S VOLTS PH AMPS
CONTROL
VOLTS
TEMP
RISE °F
AIR
THROW CFM
RECOM'D
MOUNTING
HT.
WT.
(LBS.)
644600
F1FUH03003
3.3
11,200
208
1
16
208
26
26'
400
9'
36
644662
H1HUH03003
240
1
14
240
644723 G1GUH03003
277
1
12
277
711487 H3HUH03C03
240
3
8
240
711494
F3FUH03C03
208
3
9
208
711401 P3PUH03CA1
480
3
4
24
644617
F1FUH05003
5
17,100
208
1
24
208
40
26'
400
36
644679
H1HUH05003
240
1
21
240
644730 G1GUH05003
277
1
18
277
644938
F2FUH05C03
208
1 or 3 24.1/14.0 208
44
644945 H2HUH05C03
240
1 or 3 20.8/12.1 240
644884 P3PUH05CA1
480
3
6
24
644624
F1FUH07CA1
7.5
25,600
208
1
36
24
42
36'
575
40
688550 H1HUH07CA1
240
1
31
24
41
644747 G1GUH07CA1
277
1
27
24
41
644792
F3FUH07C03
208
3
21
208
44
644952 H2HUH07C03
240
1 or 3 31.3/18.1 240
644891 P3PUH07CA1
480
3
9
24
644631
F1FUH10CA1
10
34,100
208
1
48
24
55
36'
575
42
644693
HIHUH10CA1
240
1
42
24
644754 G1GUH10CA1
277
1
36
24
644969
F2FUH10C03
208
1 or 3 48.1/27.8 208
644976 HF2HUH10C03 10/7.5
34,100
240
1 or 3 41.7/24.1 240
55
45
25,600
208
1 or 3 36.1/20.8 208
42
711425 P3PUH10CA1
10
34,100
480
3
12
24
55
51
644648
F1FUH12C03
12.5
42,600
208
1
60
208
49
45'
800
10'
45
644709 H1HUH12C03
240
1
52
240
644815
F3FUH12C03
208
3
35
208
644860 H3HUH12C03
240
3
30
240
711432 P3PUH12CA1
480
3
15
24
644655 F1FUH15CO3
15
51,200
208
1
72
208
59
45'
800
54
644716 H1HUH15C03
240
1
63
240
644822
F3FUH15C03
208
3
42
208
644877 H3HUH15C03
240
3
36
240
711449 P3PUH15CA1
480
3
18
24
688307
F1FUH20CA1
20
68,300
208
1
96
24
47
56'
1350
13'
55
688420 H1HUH20CA1
240
1
83
24
688314
F3FUH20CA1
208
3
56
24
688437 H3HUH20CA1
240
3
48
24
688321 P3PUH20CA1
480
3
24
24
688444
F1FUH25CA1
25
85,300
208
1
120
24
58
56'
1350
55
688338 H1HUH25CA1
240
1
104
24
688451
F3FUH25CA1
208
3
70
24
688345 H3HUH25CA1
240
3
60
24
688468 P3PUH25CA1
480
3
30
24
688475 H1HUH30CA1
30
102,390
240
1
125
24
70
56'
1350
60
688369
F3FUH30CA1
208
3
83
24
688482 H3HUH30CA1
240
3
72
24
688376 P3PUH30CA1
480
3
36
24
688406 P3PUH40CA1
40
136,500
480
3
48
24
55
56'
2275
16'
75
688789 P3PUH48CA1
48
163,800
480
3
58
24
67
56'
2275
78
