FEP Series Single Phase Hazardous Location Wall Convector
Unit with in-built EPET line voltage thermostat
(Suffix T1 or T2)
Unit with optional control section containing
disconnect, pilot light, and thermostat
(Suffix C1-TDP)
Standard Unit
Cabinet size 18” high, 9” wide.
• Bottom In - Front Out air flow.
Wall mounting bracket supplied.
Units cannot be operated in room
ambients exceeding 104
O
F (40
O
C).
Heavy duty 16 gauge steel with gray
epoxy textured powder coated finish.
9” minimum clearance from bottom of
heater to floor required.
Stainless steel cartridge element inserted
into Aluminum finned Copper sheath.
Standard unit (without EPET thermostat
or control section) is NEMA 4 rated.
Factory Installed Control Options
*Remove - RA suffix and add new suffix. **Remove - RA suffix and add new suffix (Not NEMA washdown rated or rated for Group B atmospheres)
Suffix “T” is 22 Amps maximum.
Manufactured in U.S.A.
*Items may not be used with 22 Amp line voltage thermostat
T-2A SERIES SINGLE PHASE
Class 1, Group B, C & D Division 1 & 2 280° C / 536° F
UPC
MODEL
WATTS BTU's VOLTS AMPS
CABINET WT.
(LBS.)
686334
LENGTH
445146 FEP-1812-1RA
1800 6143
120
15.0
34”
50
445153 FEP-1820-1RA
208
8.7
445160 FEP-1824-1RA
240
7.5
445177 FEP-1827-1RA
277
6.5
445184 FEP-1848-1RA
480
3.8
445191 FEP-3620-1RA
3600 12286
208
17.3
34”
54
445207 FEP-3624-1RA
240
15.0
445214 FEP-3627-1RA
277
13.0
445221 FEP-3648-1RA
480
7.5
445238 FEP-3657-1RA
600
6.0
445245 FEP-3820-1RA
3800 12969
208
18.3
58”
80
445252 FEP-3824-1RA
240
15.8
445269 FEP-38271-RA
277
13.7
445276 FEP-3848-1RA
480
7.9
445283* FEP-7620-1RA
7600 25938
208
36.5
58”
85
445290* FEP-7624-1RA
240
31.7
445306* FEP-7627-1RA
277
27.4
445313 FEP-7648-1RA
480
15.8
445320 FEP-7657-1RA
600
12.7
T-3A SERIES SINGLE PHASE
Class 1, Group B, C & D Division 1 & 2 180° C / 356° F
445337 FEP-0812-1RA
800
2730
120
6.7
34”
50
445344 FEP-0820-1RA
208
3.8
445351 FEP-0824-1RA
240
3.3
445368 FEP-0827-1RA
277
2.9
445375 FEP-0848-1RA
480
1.7
445382 FEP-1612-1RA
1600 5460
120
13.3
34”
54
445399 FEP-1620-1RA
208
7.7
445405 FEP-1624-1RA
240
6.7
445412 FEP-1627-1RA
277
5.8
445429 FEP-1648-1RA
480
3.3
445436 FEP-1657-1RA
600
2.7
445443 FEP-1712-1RA
1700 5802
120
14.2
58”
80
445450 FEP-1720-1RA
208
8.2
445467 FEP-1724-1RA
240
7.1
445474 FEP-1727-1RA
277
6.1
445481 FEP-1748-1RA
480
3.5
445498 FEP-3420-1RA
3400 11604
208
16.3
58”
85
445504 FEP-3424-1RA
240
14.2
445511 FEP-3427-1RA
277
12.3
445528 FEP-3448-1RA
480
7.1
445535 FEP-3457-1RA
600
5.7
SUFFIX*
DESCRIPTION
SUFFIX**
DESCRIPTION
T1
EPETD8S single pole thermostat factory mounted to
120V - 480V units
C1-TD Control section with transformer, 24V contactor, SP thermostat
(40
O
F - 90
O
F) and disconnect switch (all units)
T2
EPETD8D double pole thermostat factory mounted to
120V - 480V units
C1-TDP Control section with transformer, 24V contactor, SP thermostat
(40
O
F - 90
O
F), disconnect switch & pilot light (all units)
