5100 Series Horizontal or Vertical Mounted Fan Forced Unit Heater
Standard Taskmaster Models & Series Notes
International Models
• For 24V control add “CA1” suffix. • For 120V control add “CA2” suffix. • For other voltages consult factory.
NOTES:
25-50KW models are wired for single or two stage heating and have two speed motors.
• Air delivery and motor data on dual voltage units reflect higher voltage.
600 Volt models available in 5 KW through 30 KW. Contact factory for delivery.
Supply wire on 40 and 50 KW models should have rated insulation of 75 o C minimum.
Use T5122 for two stage control.
Use TW123 for two stage control.
Use TFS5102 for two stage control.
• Wall thermostat must be used when built-in stratification thermostat is required.
UPC#
686334
MODEL
KW BTU / H VOLTS PH AMPS CONTROL
VOLTAGE
TEMP
RISE
AIR
THROW CFM
RECOMMENDED
MOUNTING HT.
WT.
(LBS.)
Horizontal
Vertical
645089
F1F5103N
3.3
11.2
208
1
15.9
208
26
o
F 12’
400
9’
9’
25
645102 HF1B5103N 3.3/2.5 11.2 / 8.5 240/208 1 13.7 / 11.9 240 / 208
645683
F2F5103N
3.3
11.2
208 1 / 3 11.9 / 6.9
208
645706 HF2B5103N 3.3/2.5 11.2 / 8.5 240/208 1 / 3 13.7 / 11.9 240 / 208
3 7.9 / 6.9
645720 G1G5103N 3.3
11.2
277
1
11.9
277
645126 P3P5103CA1N
480
3
4.0
24
645546
F1F5105N
5.0
17.1
208
1
24.1
208
40
o
F 12’
400
9’
9’
25
645560 HF1B5105N 5.0/3.7 17.1 / 12.8 240/208 1 20.9 / 18.1 240 / 208
645140
F2F5105N
5.0
17.1
208 1 / 3
24.1
208
3
13.9
645164 HF2B5105N 5.0
17.1
240
1 / 3
20.8 / 18.1
240
27
3.7
12.8
208
1 / 3
12.1 / 10.4
208
645843 G1G5105N 5.0
17.1
277
1
18.1
277
645188 P3P5105CA1N 5.0
17.1
480
3
6.1
24
645201 F2F5107CA1L 7.5
25.6
208 1 / 3 36.1 / 20.8
24
34°F 22’
700
10’
12’
54
645225 HF2B5107CA1L 7.5
25.6
240 1 / 3 27.1 / 31.3
5.6
19.2
208 1 / 3 31.3 / 27.1
645928 G1G5107CA1L 7.5
25.6
277
1
27.1
645249 P3P5107CA1N 7.5
25.6
480
3
9.1
645263 F2F5110CA1L 9.9
33.8
208 1 / 3 47.8 / 27.4
45°F 22’
700
10’
14’
55
645287 HF2B5110CA1L 10.0
34.1
240 1 / 3 41.2 / 24.0
7.5
25.6
208 1 / 3 36.1 / 20.8
645645 G1G5110CA1N 10.0
34.1
277
1
36.1
645300 P3P5110CA1N 10.0
34.1
480
3
12.1
645324 F3F5115CA1L 15.0
51.2
208
3
41.7
1100
64
645348 HF3B5115CA1L 15.0/11.2 51.2 / 38.4 240/208 3 36.1 / 31.3
43°F 32’
11’
20’
645362 P3P5115CA1N 15.0
51.2
480
3
18.1
645386 HF3B5120CA1L 19.7/14.8 67.2 / 50.5 240/208 3 47.8 / 41.1
57°F 32’
1100
12’
18’
65
645409 P3P5120CA1N 20.0
68.3
480
3
24.1
645881 F3F5125CA1L 25.0
85.3
208
3
69.5
2000/1800
645942 HF3B5125CA1L 25.0/18.7 85.3 / 64.0 240/208 3 60.2 / 52.1
40/44°F 45’
12’
22’
120
645980 P3P5125CA1N 25.0
85.3
480
3
30.1
645423 F3F5130CA1L 30.0
102.4
208
3
83.4
2000/1800
645447 HF3B5130CA1L 30.0/22.5 102.4 / 76.8 240/208 3 72.3 / 62.5
47/53°F 40’
12’
20’
120
645461 P3P5130CA1N 30.0
102.4
480
3
36.2
644044 F3F5140CA1L 40.0
136.5
208
3
111.2
644068 HF3B5140CA1L 40.0/30.0 136.5/102.4 240/208 3 96.4 / 83.4
40/45°F 55’
3100/2800
15’
24’
120
644082 P3P5140CA1N 39.0
133.1
480
3
47.0
645485 F3F5150CA1L 49.6
169.3
208
3
139.0
645508 HF3B5150CA1L 50.0/37.5 170.6/128.0 240/208 3 120.5/104.3
51/56°F 50’
3100/2800
15’
22’
120
645522 P3P5150CA1N 50.0
170.6
480
3
60.3
UPC#
686334
MODEL
KW BTU/H VOLTS PH AMPS CONTROL
VOLTAGE
TEMP
RISE
AIR
THROW CFM
RECOMMENDED
MOUNTING HT.
WT.
(LBS.)
Horizontal
Vertical
715300 Q3H5103CA1
3.3
11263 380
3
5.02
24
26
12’
400
9’
9’
25
724920 R3H5103CA1
415
4.6
724937 Q3H5105CA1
5.0
17065 380
7.6
40
27
424944 R3H5105CA1
415
6.96
717137 Q3H5107CA1
7.5
25600 380
11.4
34
22’
700
10’
12’
54
724951 R3H5107CA1
415
10.5
686570 Q3H5110CA1 10.0
34130 380
15.2
45
10’
14’
55
724968 R3H5110CA1
415
13.9
724975 Q3H5115CA1 15.0
51195 380
22.8
43
32’
1100
11’
20’
64
724982 R3H5115CA1
415
20.9
704175 Q3H5120CA1 20.0
68260 380
30.4
57
12’
18’
65
724999 R3H5120CA1
415
27.85
719193 Q3H5125CA1 25.0
85325 380
38.0
40/44 45’
2000/1800
12’
22’
120
710619 R3H5125CA1
415
34.8
725002 Q3H5130CA1 30.0 102390 380
45.6
47/53 40’
12’
20’
710626 R3H5130CA1
415
41.8
725019 Q3H5140CA1 40.0 136520 380
60.85
40/45 55’
3100/2800
15’
24’
709835 R3H5140CA1
415
55.7
