Unit with optional control section containing
disconnect, pilot light, and thermostat
(Suffix C1-TDP)
Standard Unit
FEP Series Three Phase Hazardous Location Wall Convector
Dimensions:
Height 5 5/8’’, Width 6 3/8’’, Depth 4 1/2’’
Finish:
Silver-Gray
Type:
Single or Double Pole
Remote Mounted Hazardous Location Thermostats For Single Phase Models Only
Cabinet size 18” high, 9” wide.
• Bottom In - Top Out air flow.
Wall mounting bracket supplied.
Units can not be operated in room ambients exceeding 104
O
F (40
O
C).
• Heavy duty 16 gauge steel with gray epoxy textured powder coated finish.
• 9” minimum clearance from bottom of heater to floor required.
• Stainless steel cartridge element inserted into Aluminum finned Copper sheath.
Standard unit (without EPET thermostat or control section) is NEMA 4 rated.
Motor Rating:
(full load) 1 1/2 HP @ 250V
Rating: 22A@ 125-277VAC; 125VA@ 24VAC
Rated: Class I Group C & D, Class II Group E, F, G
Thermostat is not rated for use in Group B environments.
EPET Series Parameters
HLT Series
ABS (American Bureau of Shipping) type approved.
*T1 and T2 option not available on 3 phase models
Factory Installed Control Options
**Remove - RA suffix and
add new suffix (Not NEMA
washdown rated or rated for
Group B atmospheres)
Note: C1-TD and C1-TDP are only options available for 3 phase units.
Note: Controls mounted on the left side
only.
T-2A SERIES THREE PHASE
Class 1, Group B, C, & D Divisions 1 & 2 280° C / 536° F
UPC
MODEL
WATTS BTU's VOLTS AMPS CABINET WT.
(LBS.)
686334
LENGTH
483056
FEP-1820-3RA
1800 6143
208
5.0
34”
50
483063
FEP-1824-3RA
240
4.3
486224
FEP-1848-3RA
480
2.2
483070
FEP-3620-3RA
3600 12286
208 10.0
34”
54
483087
FEP-3624-3RA
240
8.7
486231
FEP-3648-3RA
480
4.3
483094
FEP-3820-3RA
3800 12969
208 10.5
58”
80
483100
FEP-3824-3RA
240
9.1
486248
FEP3848-3RA
480
4.6
483117
FEP-7620-3RA
7600 25938
208 21.1
58”
85
483124
FEP-7624-3RA
240 18.3
486255
FEP-7648-3RA
480
9.2
T-3A SERIES THREE PHASE
Class 1, Group B, C & D Division 1 & 2 180° C / 356° F
483131
FEP-0820-3RA
800 2730
208
2.2
34”
50
483148
FEP-0824-3RA
240
1.9
486262
FEP-0848-3RA
480
0.9
483155
FEP-1620-3RA
1600 5460
208
4.4
34”
54
483162
FEP-1624-3RA
240
3.8
486279
FEP-1648-3RA
480
1.9
483179
FEP-1720-3RA
1700 5802
208
4.7
58”
80
483186
FEP-1724-3RA
240
4.1
486286
FEP-1748-3RA
480
2.0
483193
FEP-3420-3RA
3400 11604
208
9.4
58”
85
483209
FEP-3424-3RA
240
8.2
486293
FEP-3448-3RA
480
4.1
UPC#
686334
MODEL
DESCRIPTION LOAD RATINGS
RANGE
538077
EPETD8D
DPDT - Bi-Metal
22A @120-277VAC
50-90
o
F
538107
EPETD8S
SPDT - Bi-Metal
22A @120-277VAC
50-90
o
F
528078
EPETP8D
DPDT - Bi-Metal
22A @120-480VAC
50-90
o
F
528061
EPETP8S
SPDT - Bi-Metal
22A @120-480VAC
50-90
o
F
523158
HLT-1
SPDT - Capillary
22A @120-277VAC
40-110
o
F
523165
HLT-2
DPDT - Capillary
22A @120-277VAC
40-110
o
F
Master ctn: 4 pcs, 24 lbs (varies slightly by model), 16” x 14.5” x 6”
EPET Series incorporates plastic knob & Bi-Metal Sensor housing.
HLT Series incorporates screwdriver temperature adjustment slot and all metal housing. External bulb and capillary sensor.
SUFFIX**
DESCRIPTION
C1-TD Control section with transformer, 24V contactor, SP thermostat (40
O
F - 90
O
F) and disconnect switch (all units)
C1-TDP Control section with transformer, 24V contactor, SP thermostat (40
O
F - 90
O
F), disconnect switch & pilot light (all units)
