PD Series Packaged Duct Heater
Standard Features
Galvanized Steel Element Rack - Always 1”
shorter than duct height and 1/2” shorter than
duct width to allow insertion clearance
Galvanized Steel Compartment with 1/2”
fiberglass Insulation & Hinged Cover
Door Interlock Disconnect Switch
Primary Automatic Reset Temp Limiting
Control
Load Carrying Secondary over Temperature
Protective Device(s)
• Definite Purpose Magnetic Contactor(s)
Differential Pressure Fan Inter-lock Switch
Step Down Control Transformer / 24 Volt
Permanently Attached Wiring Diagram on
inside of Terminal Compartment Cover
Manufactured in U.S.A.
Standard Models
UPC
686334 MODEL NUMBER KW
POWER
VOLTS/
PHASE
DUCT
WIDTH
W
DUCT
HEIGHT
A
DIMENSIONS
AMPS CONTROL
STEPS
WT.
(LBS.)
C
E
M
617000
PD5-128-1
5
240-1
12
8
4.75
6.5
26
20.9
1
22
617017
PD10-1810-1
10
18
10
4.75
6.5
28
41.7
2
37
617024
PD15-1812-1
15
18
12
4.75
6.5
27
62.5
2
33
617031
PD20-2012-1
20
20
12
9.125
7.5
31
83.3
2
37
617048
PD25-2016-1
25
20
16
9.125
7.5
38
104.2
3
56
617055
7PD2-128-1
2
277-1
12
8
4.75
6.5
26
7.2
1
21
617062
7PD3.5-128-1
3.5
12.6
617079
7PD5-128-1
5
18.1
617086
8PD5-128-3
5
208-3
12
8
4.75
6.5
26
13.9
1
22
617093
8PD10-1810-3
10
18
10
4.75
6.5
22
27.8
1
27
617109
8PD15-1812-3
15
18
12
9.125
6.5
25
41.7
1
32
617116 8PD15-1812-2-3
15
18
12
9.125
6.5
28
41.7
2
34
617123
8PD20-2012-3
20
20
12
9.125
6.5
40
55.6
2
39
617130
8PD25-2016-3
25
20
16
9.125
6.5
29
69.5
2
58
617147 8PD30-2416-2-3
30
24
16
9.125
7.5
29
83.4
2
65
617154
8PD30-2416-3
30
24
16
9.125
7.5
35
83.4
3
60
617437
8PD35-2416-3
35
24
16
9.125
7.5
35
97.3
3
65
617321
8PD40-2416-3
40
24
16
9.125
7.5
43
111.2
3
75
617338
8PD45-3016-3
45
30
16
9.125
7.5
43
125.1
3
80
617345
8PD50-3016-3
50
30
16
9.125
7.5
43
139
3
85
617161
PD-128-3
5
240-3
12
8
4.75
6.5
26
12.1
1
21
617178
PD10-1812-3
10
18
10
4.75
6.5
22
24.1
1
26
617185
PD15-1812-1-3
15
18
12
4.75
6.5
20
36.2
1
30
617192
PD15-1812-2-3
15
18
12
9.125
6.5
26
36.2
2
33
617208
PD20-2012-3
19.9
20
12
9.125
6.5
28
47.9
2
39
617215
PD25-2016-3
25
20
16
9.125
6.5
29
60.2
2
57
617222
PD30-2416-2-3
30
24
16
4.75
6.5
25
72.3
2
57
617239
PD30-2416-3-3
30
24
16
9.125
6.5
35
72.3
3
65
617352
PD35-2416-3
35
24
16
9.125
7.5
35
84.3
3
65
617369
PD40-2416-3
40
24
16
9.125
7.5
35
96.3
3
75
617376
PD45-3016-3
45
30
16
9.125
7.5
43
108.4
3
80
617383
PD50-3016-3
49.8
30
16
9.125
7.5
43
120
3
85
617246
4PD5-128-3
5
480-3
12
8
4.75
6.5
26
6.1
1
21
617253
4PD10-1810-3
10
18
10
4.75
6.5
22
12.1
1
26
617260
4PD15-1812-3
15
18
12
4.75
6.5
20
18.1
1
30
617277 4PD15-1812-2-3
15
18
12
9.125
6.5
26
18.1
2
34
617284
4PD20-2012-3
20
20
12
9.125
6.5
26
24.1
2
39
617291
4PD25-2016-3
25
20
16
9.125
6.5
22
30.1
2
58
617307 4PD30-2416-2-3
30
24
16
4.75
6.5
18
36.2
2
65
617314 4PD30-2416-3-3
30
24
16
9.125
6.5
24
36.2
3
65
617390
4PD35-2416-3
35
24
16
9.125
6.5
26
42.2
3
65
617406
4PD40-2416-3
39.9
24
16
9.125
6.5
40
48.1
3
75
617420
4PD50-3016-3
50
30
16
9.125
6.5
36
60.2
3
85
