HOW TO DESIGNATE A MODEL:
Series Number
Element KW
3KW through 50KW
See model chart for KW options.
Element Voltage
F = 208V H = 240V G = 277V P = 480V
Phase
1 = Single Phase 3 = Three Phase
Control System
Blank = None
T = Unit Thermostat
SSR = SSR Control
Motor Voltage
E = 120 G = 277 P = 480
Heater Stages
Blank = One 2 = Two
F 3 E 72 15 2 T
7200 Series Plenum Heater
Product Specifications
20 gauge galvanized cabinet.
Variable speed motor, factory set at maximum. Motor speed
can be field adjusted to increase heat rise.
• Acoustically insulated with 1” fiberglass.
Access panels on both sides of cabinet.
24 Volt controls.
• Air flow switch.
Terminal blocks.
Single point connection.
Dust tight control enclosure.
• Filter rack on inlet with throw away filter.
Inlet and outlet screens and duct connection.
Automatic primary limit control and secondary fuse link.
Optional wall thermostat, unit thermostat or SSR control
which proportionally regulates heat output.
Disconnect switch.
Manufactured in U.S.A.
Standard Models
SSR proportional control maximum: 45 Amps
Note: Products listed in this section are custom built and subject to 100% cancellation/restock charges.
UPC#
686334
MODEL
KW CFM RANGE VOLTS /
PHASE
TOTAL
AMPS for
MOTOR &
HEATER
STAGE MOTOR
VOLTAGE
FULL LOAD
AMPS for
MOTOR ONLY
MOTOR H.P.
WT.
(LBS)
617680
F1G7203
3
70-270
208/1
15.4
1
277
1
1/15
98
606561
H1G7203
240/1
13.5
277
1
606240
G1G7203
277/1
11.83
277
1
606905
F3G7203
208/3
9.32
277
1
617765
H3G7203
240/3
8.21
277
1
617574
P3G7203
480/3
4.6
277
1
617666
F1G7205
5
200-650
208/1
25.13
1
277
1.1
1/6
118
617956
H1G7205
240/1
21.93
277
1.1
606165
G1G7205
277/1
19.15
277
1.1
606424
F3G7205
208/3
14.97
1
277
1.1
617994
H3G7205
240/3
13.12
277
1.1
606110
P3G7205
480/3
7.11
277
1.1
606554
F3E7210
10 500-1200
208/3
33.05
1
120
5.3
1/4
141
617734
H3G7210
240/3
25.75
277
1.7
617581
P3G7210
480/3
13.72
277
1.7
606516
F3E7210-2
208/3
33.05
2
120
5.3
534390
H3G7210-2
240/3
25.75
277
1.7
617659
P3G7210-2
480/3
13.72
277
1.7
608602
F3E7215
15 500-1200
208/3
46.93
1
120
5.3
608848
H3G7215
240/3
37.78
277
1.7
606257
P3G7215
480/3
19.74
277
1.7
606943
F3E7215-2
208/3
46.93
2
120
5.3
534406
H3G7215-2
240/3
37.78
277
1.7
606066
P3G7215-2
480/3
19.74
277
1.7
608831
F3E7220-2
20 750-1600
208/3
63.81
2
120
8.3
1/2
163
534413
H3G7220-2
240/3
50.61
277
2.5
606394
P3G7220-2
480/3
26.55
277
2.5
534420
F3E7223-2
23 1300-2000
208/3
74.84
2
120
11
3/4
201
617888
H3G7223-2
240/3
59.63
277
4.3
606875
P3G7225-2
25
480/3
34.37
277
4.3
534437
H3G7230-2
30 1800-2800
240/3
78.47
2
277
6.3
2 MOTORS @
1/2 H.P. EACH 278
606745
P3G7230-2
480/3
42.38
277
6.3
618007
P3G7235-2
35
480/3
48.39
277
6.3
606851
P3G7240-2
40
2000-3600
480/3
56.71
2
277
8.6
2 MOTORS @
3/4 H.P. EACH 319
534444
P3G7245-2
45
480/3
62.72
277
8.6
606417
P3G7250-2
50
480/3
68.74
277
8.6
