89
5"
7"
3"
8.75"
48"
CORD LENGTH: 6'10"
16AWG USASI HPN CORD
CORD LENGTH: 25'
18AWG SHIELDED CABLE
H
L
W
HANDLE ADDS 6" TO L"
10.625"
5"
7"
3"
8.75"
48"
CORD LENGTH: 6'10"
16AWG USASI HPN CORD
CORD LENGTH: 25'
18AWG SHIELDED CABLE
H
L
W
HANDLE ADDS 6" TO L"
10.625"
H
L
W
H
L
W
H
L
W
H
L
W
Thermal Area Treatment Heaters
Standard Models
Product Dimensions
MODEL
DIMENSIONS
WT. (LBS)
LENGTH
WIDTH
HEIGHT
TAT-8-240-1
39”
26.5”
18”
180
TAT-5-240-1
39”
26.5”
18”
180
TAT-20-480-3
39”
30.5
18”
234
TAT-1-120-1
48”
8.5”
9.5”
23
Remote Timer
11”
3”
4.5”
5
TAT 30, 45
37”
24”
39”
115/125
TAT24-FAN-120V-1
10.5”
26”
26”
30
*208 Volt models do not have a cord supplied
Accessories
Single speed
Head tilts 360
o
Coated steel guards
SJT type 3 conductor
Steel hub / Aluminum blades
Meets OSHA standards
TAT-24-FAN-120V-1
TAT 30-45
Safety yellow heater enclosure with safety screens
on both air intake and output openings.
Optional 25’ long SO type cord, ready for plug
attachment is available for each model.
• Long-life finned tubular heating elements.
Thermostat adjustment 120° to 150° F.
Two 10” rear wheels and a front locking caster.
High-limit thermal cutout switch with manual reset.
2200 CFM
Fan only operation feature
UPC#
686334
STYLE MODEL
NUMBER
BASE
UNIT
KW
BASEBOARD
PERIMETER
HEATER KW
TOTAL
SYSTEM
KW
BASE
UNIT
VOLTS
BASEBOARD
PERIMETER
HEATER
VOLTS
PHASE
BASE
UNIT
AMP
BASEBOARD
PERIMETER
AMP-EACH
CIRCUIT (3)
PLUG TYPE
BASE UNIT PERIMETER
397568 TAT5-240-1/3BB/1T 5.3
1.5 (X3)
9.8 240
120
1
24
12.5
Nema 10-30 Nema 5-15
397629 TAT5-208-1/3BB/1T* 5.3
1.5 (x3)
9.8 208
120
1
27
12.5
----
Nema 5-15
397551 TAT8-240-1/3BB/1T 8.4
1.5 (X3)
12.9 240
120
1
37
12.5
Nema 14-50 Nema 5-15
397612 TAT8-208-1/3BB/1T* 8.4
1.5 (x3)
12.9 208
120
1
42
12.5
----
Nema 5-15
397520 TAT20-480-3/3BB/1T 20
1.5 (X3)
24.5 480
120
3
26
12.5
Nema L16-30 Nema 5-15
397582 TAT-ILC-25
25’ Shielded Cable
UPC#
686334
MODEL
DESCRIPTION
HP
CFM / RPM MAX AMPS VOLTS WT (LBS)
397636 TAT-24-FAN-120V-1 Thermal Area Treatment Floor Fan
1/3
5000/1160
3.1
120
30
UPC#
686334
MODEL
DESCRIPTION
KW BTU VOLTS PHASE AMPS TEMP RISE WT (LBS)
397834
TAT-30
30KW Salamander
30
102390
480
3
36
43
115
397841
TAT-45
45KW Salamander
45
153585
480
3
54.2
70
125
