Thermostats & Controls
RK Series - Low Voltage
Features
Fahrenheit and Celsius temperature
scales
2-3
o
F rated differential
Heat only models
Positive off
Low Voltage Relays
Features
Built-In transformer
45 second average time delay
Temperature range - 50
o
- 90
o
F
UT Series - Low Voltage
Features
Fahrenheit and Celsius temperature
scales
2-3
o
F rated differential
Anticipator (except UT9001)
Vertical or horizontal mounting
Long life sealed contacts
Does not contain Mercury
Leveling not required
Standard Models
Standard Models
Standard Models
Features
8 tumbler locks
TG Series Thermostat Guards
Standard Models
Snap action switch
1/2” male conduit spud
Does not contain Mercury
Leveling not required
Long life sealed contacts
Two switch unit shown.
UPC#
686334 MODEL DESCRIPTION VOLTAGE TERMINALS
SWITCHES
523059 UT1001
Heat Only 24VAC or MV R &W
None
523066 UT3001 Cool Only
24 VAC
R, Y & G
Cool/Off Fan/Auto
523134 UT6001
Deadband
24 VAC
R, W & Y
None
523073 UT8001
Heat/Cool
24 VAC RC, RH, W, Y, & G Heat/Off/Cool Fan/Auto
523110 UT9001
Heat Only
Millivolt
R & W
None
Master Carton: 50 pcs, 17 lbs, 19” x 11.5” x 9”
UPC #
686334
MODEL DESCRIPTION VOLTAGE RANGE ANTICIPATOR
526012 RK120EAA Heat Only
24VAC or MV 50
o
-90
o
F
Yes
526203 RK124EAA Heat Only
24VAC or MV 35
o
-75
o
F
Yes
526050 RK130EAA Heat Only
Millivolt
50
o
-90
o
F
No
526326 RK134EAA Heat Only
Millivolt
35
o
-75
o
F
No
526142 RKWP1AA Wall Plate
NA
NA
NA
Master Carton: 100 Pcs, 24 lbs, 16.5” x 15” x 8”
UPC#
686334 MODEL PRIMARY
VOLTAGE
DESCRIPTION
260039 24A05A-1 120 Volts
Single Switch, single throw with In-Built Transformer for remote
mounting or in a factory provided optional enclosure
260046 24A05E-1 208 Volts
260053 24A01G-3 240 Volts
260107 24A06G-1 240 Volts Two switch, single throw with In-Built Transformer, 25 Amps per
switch
UPC#
686334
MODEL
DESCRIPTION
589123
TG1
Plastic Stat Guard/ 6.25” x 3.625” x 3.25” Opening
589109
TG1B
Metal Stat Guard/ 5.25” x 4.625” x 3” Opening
589130
TG2
Plastic Stat Guard/ 5.25” x 4.625” x 3.25” Opening
589161
TG2B
Metal Stat Guard/ 6.25” x 3.625” x 3.25” Opening
589116
TG3
Plastic Stat Guard/ 8.125” x 4.625” x 3.625” Opening
589178
TG3B
Metal Stat Guard/ 6.75” x 4.50” x 3.50” Opening
523615
TG4
Plastic Stat Guard / 3.50” x 3.937” x 1.75” Opening
523622
TG5
Plastic Stat Guard / 5” x 3.31” x 1.75” Opening
523639
TG6
Plastic Stat Guard / 5.75” x 4.625” x 1.75” Opening
