TPI Industrial Heavy Duty Direct Drive Blowers
Features
• Totally enclosed and explosion proof motors
• Explosion proof motors are Class 1, Div 1, Group D and
Class 2, Div 1, Groups F & G
• Cast Aluminum props
• 14 gauge steel body and stand
• Acid resistant coating available
• Baked enamel coating
• 360° Swivel on high and medium stand units
• Meets federal OSHA requirements
• 1 year limited warranty
LOW STAND
HIGH STAND
MEDIUM STAND
NOTE:
Single phase motors are field convertible 115V / 230V
Three phase motors are field convertible 230V / 460V
Motors are set to lower voltage at the factory unless a request is
made at time of order to set to the higher voltage
Standard Models
Manual Starter Switches
Polyolifin Casters
(FOR LOW & MEDIUM STAND)
4 CASTERS - 2 LOCKING
Note: Products listed in this section are custom built and subject to 100% cancellation/restocking charges.
SIZE
MFG
MODEL
NUMBER
HP RPM CFM DB’s
@ 10’
WT. (LBS)
LIST
STAND
TEC
EXP
TEC
EXP
TEC
EXP
LOW MED HIGH
1PH 3PH 1PH 3PH 1PH 3PH 1PH 3PH 1PH 3PH 1PH 3PH
MODEL NUMBER SUFFIX’S
-L -L-3 -L -L-3 -M -M-3 -M -M-3 -H -H-3 -H -H-3
18”
MCD18-1/4 1/4 1725 3050 74 103 145 210
2732 2720 3145 3211 3368 3355 3774 3850 3675 3663 4090 8278
MCD18-1/3 1/3 1725 3450 76 105 150 215
2825 2849 3362 3500 3459 3479 3996 4142 3768 3787 4310 7800
MCD18-1 1 1725 4600 77 117 165 230
3187 3070 3780 3850 3828 3704 4410 4485 4135 4014 4723 4794
24”
MCD24-1/4 1/4 1725 5200 80 115 165 230
2796 2785 3199 3279 3513 3508 3914 3996 3763 3594 4165 4247
MCD24-1/3 1/3 1140 5300 74 126 175 250
3245 3279 4124 4171 3960 3996 4839 4888 4211 4084 5090 5137
MCD24-1/2 1/2 1725 6000 80 120 170 240
3030 3041 3659 3594 3746 3758 4374 4310 3996 3850 4624 4560
MCD24-3/4 3/4 1140 6900 74 140 190 260
3868 3500 4385 4265 4584 4222 5103 4981 4834 4310 5352 5230
MCD24-1 1 1725 7400 82 130 180 250
3286 3169 3873 3943 4002 3885 4589 4659 4252 3973 4839 4909
MCD24-1 1/2 1.5 1725 8200 84 137 190 255
3473 3320 5132 4217 4188 4042 5848 4933 4439 4130 6098 5183
MCD24-3 3 1725 10500 87 160 210 270
---- 3624 ---- 4584 ---- 4340 ---- 5307 ---- 4433 ---- 5550
30”
MCD30-1/3 1/3 1140 6900 80 150 205 260
3559 3594 4439 4485 4345 4380 5225 5277 4659 4694 5533 5586
MCD30-1/2 1/2 1725 8900 86 141 195 250
3349 3362 3979 3914 4142 4152 4769 4708 4451 4461 5078 5015
MCD30-3/4 3/4 1140 10400 80 210 260 320
4096 3734 4608 4490 4881 4520 5400 5282 5190 4828 5708 5592
MCD30-1 1 1140 11200 81 200 260 310
4909 3938 5854 4659 5702 4728 6645 5445 6010 5038 6953 5754
MCD30-1 1/2 1.5 1725 12000 92 200 250 310
3780 3629 5440 4526 4566 4422 6232 5317 4874 4728 6540 5626
MCD30-2 2 1140 14000 84 225 270 330
---- 4211 ---- 5242 ---- 5003 ---- 6034 ---- 5312 ---- 6343
MCD30-3 3 1725 16000 94 220 265 325
---- 3855 ---- 4817 ---- 4648 ---- 5608 ---- 4958 ---- 5913
36”
MCD36-1 1 1140 13000 82 250 320 375
5545 4573 6488 5289 6517 5550 7466 6268 6722 5749 7664 6465
MCD36-1 1/2 1.5 1725 14850 88 250 320 375
4385 4235 6045 5132 5359 5207 7018 6104 5562 5411 7222 6309
MCD36-2 2 1140 17500 82 255 325 380
---- 4678 ---- 5713 ---- 5655 ---- 6686 ---- 5854 ---- 6890
MCD36-3 3 1725 18500 90 260 330 390
---- 4468 ---- 5428 ---- 5440 ---- 6406 ---- 5643 ---- 6605
MCD36-5 5 1725 23000 94 260 330 390
---- 4544 ---- 5598 ---- 5515 ---- 6570 ---- 5713 ---- 6768
42” MCD42-2 2 1140 19500 85 315 415 565
---- 5370 ---- 6406 ---- 6406 ---- 7438 ---- 6815 ---- 7850
MCD42-5 5 1725 27000 98 320 420 570
---- 5230 ---- 6290 ---- 6268 ---- 7320 ---- 6680 ---- 7740
48”
MCD48-5 5 1140 32000 92 500 620 710
---- 7094 ---- 8835 ---- 8235 ---- 9976 ---- 8961 ---- 10704
MCD48-7 1/2 7.5 1140 37000 105 625 745 835
---- 8235 ---- 11118 ---- 9378 ---- 12259 ---- 10104 ---- 12982
MCD48-10 10 1140 41000 105 682 800 890
---- 9638 ---- 12207 ---- 10779 ---- 13342 ---- 11503 ---- 14070
60”
MCD60-3 3 690 35000 87 690 855 965
---- 15119 ---- ---- ---- 17273 ---- ---- ---- 17767 ---- ----
MCD60-5 5 690 45000 87 730 895 1005
---- 17004 ---- ---- ---- 19152 ---- ---- ---- 19653 ---- ----
MCD60-7 1/2 7.5 870 47000 90 945 1110 1220
---- 14250 ---- ---- ---- 16399 ---- ---- ---- 16894 ---- ----
MCD60-10 10 870 57200 91 1035 1200 1310
---- 17737 ---- ---- ---- 19887 ---- ---- ---- 20387 ---- ----
MCD60-15 15 870 60750 92 1080 1245 1355
---- 23200 ---- ---- ---- 25348 ---- ---- ---- 25848 ---- ----
MFG MODEL NUMBER
H.P.
RATING
LIST PRICE
TEC
1 PH
3 PH
1 PH
3 PH
SW-1/4
SW-1/4-3
1/4-1/3
527
1257
SW-1/2
SW-1/2-3
1/2-3/4
527
1257
SW-1
SW-1-3
1
527
1257
SW-1 1/2
SW-1 1/2-3
1.5
1236
1257
-----
SW-2-3
2
----
1257
-----
SW-3-3
3
----
1257
-----
SW-5-3
5
----
1257
-----
SW-7 1/2-3
7.5
----
1193
MFG
MODEL
NUMBER
FAN SIZE WHEEL
SIZE
WT.
(LBS)
LIST
CAS - 18 18” - 30”
4”
10
505
CAS - 48 36” - 48”
5”
14
711
