TPI Industrial Direct Drive Suspension Blowers
Features
• On-Off rocker switch
• SJT type 3 conductor, 12’ long cord
• Aluminum blade
• Powder coated spiral wire front and rear guards
• Corrosion and dent proof high density polyethylene housing
• Spiral wire front and rear guards
• Meets OSHA standards
• 1 year limited warranty
• Made in U.S.A.
Motor Specifications
• 120V., 1-Phase
• Ball bearing
• Permanent split capacitor
• 2-Speed on 30” & 36” model
• 1-Speed on 42” model
• Permanently lubricated
Standard Models
TPI Industrial Belt Drive Suspension Blowers
Features
• On-Off rocker switch on 120V, 1-Phase models
• SJT type 3 conductor, 12’ long cord on 120V, 1 phase models
• No cord on dual voltage models
• Aluminum blade
• Powder coated front and rear guards
• Corrosion and dent proof high density polyethylene housing
• Powder coated spiral wire front and rear guards
• Meets OSHA standards
• 1 year limited warranty
• Mounting chain not included.
• Made in U.S.A.
Motor Specifications
• 120V., 1-Phase
• Ball bearing
• Permanent split capacitor
• 2-Speed on 30” & 36” model
• 1-Speed on 42” model
• Permanently lubricated
Standard Models
Note: Products listed in this section are custom built and subject to 100% cancellation/restocking charges.
Note: Photograph is a representation of stocked models. Actual model may vary slightly in appearance.
*Models have no listing.
SIZE MOTOR
HP
MFG CATALOG
NUMBER
MFG MODEL
NUMBER
CFM
RPM
HIGH
AMPS
HIGH
WT.
(LBS)
LIST
HIGH
LOW
30”
1/4
08748802
SB 30-D
6,000
4,800
1050
2.5
58
654
36”
1/3
08730602
SB 36-D
7,000
5,900
1050
5.6
70
760
42”
1/2
08730902
SB 42-D
10,000
825
7.9
99
1070
External junction boxes on dual voltage models allow units to be wired for either voltage without removing guards.
Hazardous Location models have explosion proof motors and external junction boxes rated for Class I, Group D, & Class II,
Groups E, F & G,. (Metal housing and no switch.)
MFG CATALOG
NUMBER
MFG MODEL
NUMBER
SIZE
MOTOR
CFM RPM AMPS
WT.
(LBS)
LIST
TYPE
HP
07965502
SB 36-B
36”
115 V
1/2
9,000
500
8
120
1078
07965602
SB 42-B
42”
1 PH
3/4
13,800
430
11
135
1229
07965702
SB 48-B
48”
ODP
1
15,000
390
15
155
1380
08509802
SB 36-B-3
36”
230 / 460 V
1/2
9,000
500
2.3 / 1.1
127
1438
08509902
SB 42-B-3
42”
3 PH
3/4
13,800
430
3.3 / 1.5
143
1741
08510002
SB 48-B-3
48”
ODP
1
15,000
390
3.8 / 1.9
164
1833
08510102
SB 36-B-HL*
36”
115 / 230 V
1/2
9,000
500
7.8 / 3.9
135
2275
08510202
SB 42-B-HL*
42”
1 PH
3/4
13,800
430
10.8 / 5.4
150
2587
08510302
SB 48-B-HL*
48”
EXP
1
15,000
390
13.2 / 6.6
173
2807
