TPI Industrial Mini-Blowers
• Floor models have rotary switch
• Yoke mounted models have pull chain switch
• SJT type 3 conductor, 10’ long cord
• Aluminum blade
• Spiral, wire front and rear guards
• Corrosion and dent proof high density polyethylene housing
• Meets OSHA standards
• 1 year limited warranty
• Made in U.S.A. with domestic and foreign components.
Features
Motor Specifications
• 1-Phase
• 1/4 HP
• Ball bearing
• Totally enclosed
• 120V
• 2-Speed
• Permanently lubricated
• Permanent split capacitor
TOTALLY ENCLOSED MOTOR ALLOWS MINI-BLOWER TO BE
USED IN DIRTY OR DUSTY ENVIRONMENTS.
AVAILABLE AS FLOOR MODEL OR YOKE MOUNTED MODEL
THAT CAN BE DIRECTLY BOLTED TO ANY SURFACE OR
USED WITH OPTIONAL WALL/CEILING MOUNT.
YOKE MOUNTED
MODEL
FLOOR
MODEL
Standard Models
TPI Industrial Heavy Duty Square Belt Drive Portable Blowers
Features
• On-Off rocker switch
• SJT type 3 conductor, 12’ long cord
• Aluminum blade
• Permanently lubricated bearings on blade drive shaft
• Powder coated front and rear guards
• Powder coated 20 gauge venturi
• 18 gauge galvanized steel housing
• Meets OSHA standards / 1 Year limited warranty
• Made in U.S.A.
Motor Specifications
• 1-Phase
• Ball bearing
• Drip proof motor
• 120V
• 1-Speed
• Permanently lubricated
Standard Models
4” CASTERS
MBM-W
(optional wall/ceiling mount)
• 1/2 Shaft
SIZE
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
MOTOR
DIMENSIONS
WT.
(LBS)
LIST
HP
CFM RPM AMPS
“H”
“W”
“D”
36”
08683602
PCBT 36-B 1/2
8,100
500
8.0
48 1/4”
28 1/4”
22 1/2”
120
1675
42”
08683702
PCBT 42-B 3/4
12,400
430
11.0
56 1/2”
34 1/4”
22 1/2”
140
2177
48”
08683802
PCBT 48-B
1
13,500
390
15.0
62 1/2”
40 1/4”
18 1/2”
185
2646
MFG CATALOG
NUMBER
MFG MODEL
NUMBER
FAN
CFM / RPM
DIMENSIONS
AMPS
(High)
WT.
(LBS)
LIST
TYPE
SIZE HIGH LOW “H”
“W”
“D”
08743502
MB 24-DF
FLOOR STYLE
24”
5000 /
1140
4000 /
1070
29 1/2” 28 1/2” 14 1/4”
2.2
52
656
08743602
MB 24-DY YOKE STYLE
29” 28 1/2” 14 1/4”
52
656
08743702
MB 30-DF
FLOOR STYLE
30”
6000 /
1040 4800 / 730
38 1/2” 37 1/2” 14 1/2”
2.5
58
725
08743802
MB 30-DY YOKE STYLE
38” 37 1/2” 14 1/2”
58
725
07989002
MBM-W
OPTIONAL WALL/CEILING MOUNT FOR YOKE STYLE MINI-BLOWER
4
133
